2.4 Cooling and Heating Data Sheet in Rated Frequency

Cooling:
Rated cooling
condition(°F) (DB/WB)
Indoor Outdoor
81/66 95/75
Heating:
Rated heating
condition(°F) (DB/WB)
Indoor Outdoor
68/- 45/43
Instruction:
T1: Inlet and outlet pipe temperature of evaporator
T2: Inlet and outlet pipe temperature of condenser
P: Pressure at the side of big valve
Connection pipe length: 24.6ft.

2.5 Noise Curve

Indoor side noise
50
45
40
35
30
25
20
15
SL L M L
Indoor fan motor rotating speed
Technical Information
Pressure of gas pipe
connecting indoor
Model
and outdoor unit
PSIG
09K 123.2~145
Pressure of gas pipe
connecting indoor
Model
and outdoor unit
P (MPa)
09K 362.3~435
M MH H SH
Inlet and outlet pipe
temperature of heat
Fan speed of
exchanger
T1 (°F) T2 (°F)
in:46~52 in:122~176
out:52~57 out:99~109
Inlet and outlet pipe
temperature of heat
Fan speed of
exchanger
T1 (°F) T2 (°F)
in:122~176 in:34~37
out:99~109 out:36~41
Outdoor side noise when blowing
75
70
65
60
55
50
45
40
35
20 30
Compressor frequency(Hz)
Compressor
Fan speed of
indoor unit outdoor unit
Suprt High High
Compressor
Fan speed of
indoor unit outdoor unit
Super High High
40 50 60 70
revolution
(Hz)
58
revolution
(Hz)
56
80 90
