5. Electrical Part

5.1 Wiring Diagram

●Instruction
Symbol
WH
YE
RD
YEGN
VT
Note: Jumper cap is used to determine fan speed and the swing angle of horizontal lover for this model.
● Indoor Unit
8
Symbol Color Symbol
White GN
Yellow BN
Red BU
Yellow/Green BK
Violet OG
Symbol Color
Green
Brown
Blue
Black
Orange
Symbol Name
CAP Jumper cap
COMP Compressor
Grounding wire
/ /
/ /
6361000044202
