4. Remove detecting plate and electric box cover2
Remove the screws fixing detecting plate
and remove detecting plate.
Remove the screws fixing electric box
cober2 and remove electric box2.
Loosen the connection clasps between
front case sub-assy and bottom case.
Lift up the front case sub-assy and take
it out.
Screw off the screws that are locking
the swing motor and take the motor off.
60
Detecting plate
Bottom case
Service Manual
2
S wing motor
Installation and Maintenance
