2. Specifications

2.1 Specification Sheet

Model
Product Code
Rated Voltage
Power Supply Rated Frequency
Phases
Power Supply Mode
Cooling Capacity
Heating Capacity
Cooling Power Input
Heating Power Input
Cooling Power Current
Heating Power Current
Rated Input
Rated Current
Air Flow Volume(SH/H/MH/M/ML/L/SL)
Dehumidifying Volume
EER
COP
SEER
HSPF
Application Area
Model of indoor unit
Indoor Unit Product Code
Fan Type
Diameter Length(DXL)
Fan Motor Cooling Speed (SH/H/MH/M/ML/L/SL)
Fan Motor Heating Speed (SH/H/MH/M/ML/L/SL)
Output of Fan Motor
Fan Motor RLA
Fan Motor Capacitor
Evaporator Form
Pipe Diameter
Indoor Unit Row-fin Gap
Coil Length (LXDXW)
Swing Motor Model
Output of Swing Motor
Fuse
Sound Pressure Level (SH/H/MH/M/ML/L/SL)
Sound Power Level (SH/H/MH/M/ML/L/SL)
Dimension (WXHXD)
Dimension of Carton Box (LXWXH)
Dimension of Package (LXWXH)
Net Weight
Gross Weight
2
CB460005700_L71081
V~
Hz
Btu/h
Btu/h
W
W
A
A
W
A
CFM 424/383/353/324/294/265/206
Pint/h
(Btu/h)/W
(Btu/h)/W
2
yd
CB460N05700_L71081
inch
r/min 1250/1170/1100/1020/960/650/600
r/min 1300/1200/1120/1040/960/880/800
W
A
μF
Aluminum Fin-copper Tube
inch
inch
inch
W
A
dB (A)
dB (A)
inch 38 13/64X11 13/16X8 5/6
inch
inch
Ib
Ib
Service Manual
TW09HQ3D6D
208/230
50/60
1
Outdoor
9000
9000
540
610
3.05
3.15
1500
6.2
1.69
16.67
14.75
30.5
14
19.1-28.7
TW09HQ3D6DI
Cross-flow
Φ4 1/6X27 4/5
60
0.09
/
Φ 9/32
2-1/16
28 9/64X1X12
MP35CJ/MP24HF
2.5/1.5
3.15
46/40/38/36/33/31/19
56/50/48/46/43/41/29
40 55/64X15X12
41X15X12 39/64
29.8
36.4
