1

Key features

• Input voltage: 125 - 400 VDC
• Nominal power: up to 1200 W
– Allowable maximum power is related to the application conditions and cooling system
• Nominal current: up to 4.2 A
• Input auxiliary voltage: up to 20 V DC
• Single- or three-shunt resistors for current sensing (with sensing network)
• Two options for current sensing: dedicated op-amps or through MCU
• Overcurrent hardware protection
• IPM temperature monitoring and protection
• Hall sensor or encoder input
• MOSFET intelligent power module:
– SLLIMM™ 2nd series IPM (STIB1060DM2T-L - DBC package)
• Motor control connector (32-pin) to interface with ST MCU boards
• Universal conception for further evaluation with breadboard and testing pins
• Very compact size
• WEEE compliant
• RoHS compliant
