ATTENTION:
Fit some mounting bases to
the side of the pillars. That
means there are only 2
screws required per mounting
base and those are on the
glass side. For all interlinked
mounting bases, 4 screws
are required and thus 4 holes
need to be drilled.
➌
Use a brush to remove the aluminium drilling residue on the Velux VMS.
➍
➎
First, put a spacing bush in
each hole and then the rub-
ber. The recess in the rubber
must fit over the groove in
pillar.
Now, position the drilling jig
on the next pillar. The holes
➊
can be drilled in the same
way. Ensure that the holes
have the required depth. You
have to drill through the clad-
ding as well as the VMS
➊
profile .
➋
➋
single mounting base rubber
Topfix VMS
®
interlinked mounting base
rubber
