1. HOW DOES THIS SCREEN WORK?

The solar cell collects sunlight and converts it into energy to charge the battery. So, you can still use the screen on days
that are not as sunny thanks to the energy stored in the battery. Naturally, the solar cell must always be in a place where
it can get enough sunlight. The Fixscreen (Minimal) Solar's scope of application, therefore, is also geographically defined
based on this and on the prevailing weather conditions.

2. CAN THE FIXSCREEN (MINIMAL) SOLAR BE USED IN ANY COUNTRY?

The Fixscreen (Minimal) Solar is available worldwide, for countries between 52° Northern- and Southernlatitude (between
52° N and 52° S). This scope of application is taken from the Somfy instructions. The Fixscreen (Minimal) can be applied
in the 'not possible' zones but always check off with the Solar by Somfy app.
Any use outside of the scope of application as defined by Renson is not in conformity. Because of this and a disregard
for the instructions in the manual, any liability and warranty on Renson's behalf become null and void and the proper
operation of your Fixscreen 100 Solar cannot be guaranteed.
52° N
52° S
Frequently Asked Questions
Fixscreen
®
NOT POSSIBLE
NOT POSSIBLE
– 1 –
(Minimal) Solar
52° N
52° S
NOT POSSIBLE
52° N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fixscreen Minimal Solar and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Renson Fixscreen Minimal Solar

  • Page 1 'not possible' zones but always check off with the Solar by Somfy app. Any use outside of the scope of application as defined by Renson is not in conformity. Because of this and a disregard for the instructions in the manual, any liability and warranty on Renson’s behalf become null and void and the proper operation of your Fixscreen 100 Solar cannot be guaranteed.
  • Page 2 In below mentioned circumstances Renson recommends not to use the Fixscreen (Minimal) Solar. With Fixscreen Solar the individual solar panel can be used. A cable length of 3 or 5 m is possible to order.
  • Page 3 • Fixscreen Minimal Solar The battery can be charged in the manner shown below. Therefore, the installer only has to remove the front cover and attach the adapter’s connector to the connector in the front cover.
  • Page 4 3 m (5 m surcharge). It is also necessary to choose the position of the cable throughput. For Fixscreen Minimal Solar, this choice is not available to date. 9. HOW DO YOU PROGRAM THE MOTOR? You program this motor in the same way you program a Somfy RTS motor.
  • Page 5 Frequently Asked Questions Fixscreen (Minimal) Solar ® 12. WHICH TYPE OF MOTOR IS USED FOR THE FIXSCREEN (MINIMAL) SOLAR? The Fixscreen (Minimal) Solar is equipped with a radio-controlled Somfy RTS motor: Sunea 40 DC RTS. Power supply 12 V DC (min 11,5 V, max 14 V) Radio frequency 433,42 MHz Index protection rating...
