Renson ZipShade Medium IM7A User Manual & Warranty

Warranty certificate
Dear customer,
You have recently become the owner of a quality sunprotection screen from RENSON
We congratulate you on your wise choice. After final inspection your sunprotection screen was given the serial number that
you can find in this booklet.
All the materials we use are top quality and suitable for their purpose. As a manufacturer of sunprotection screens, we
guarantee our products for five years** against any defects occurring during normal use and maintenance.
In the event of problems, always quote the serial number to your installer.
Because RENSON Sunprotection-Screens places great importance on the quality of its products and on providing maximum
®
satisfaction for our customers and end-users, we have drawn up special operating and maintenance instructions.
This guarantee certificate shall cover :
ZipShade Medium / ZipShade
® ®
* 7- year guarantee on the ZipShade technology (excl. Freestanding (F): 5-year guarantee):
• zip remains in side guides
• maximum bonding of zip to fabric
** A 5-year guarantee also applies motors.
Concerning the coating of aluminium elements, a 10-year guarantee applies for the colour stability.
A 5-year guarantee applies on the gloss of the coated profiles.
A 2-year guarantee is given for the Crystal screen.
User manual & warranty conditions
1 • Electrical specifications
Category
Power supply
Current
Output
Protection class
Max. operating time
2 • Wind class
For information the following are the wind classes according to the DIN 13561:2004 standard.
ZipShade Medium / ZipShade
® ®
with standard fabric or blackout fabric (not freestanding).
Wind class Wind force (on Beaufort scale)
Class 0
Class 1
Class 2
Class 3
3 • Function
Sunprotection screen for external use, specially designed to exclude the sun and create an optimal internal climate.
Depending on the type of fabric selected, the values for light permeability and heat protection may vary.
The specific design of the ZipShade makes it extremely resistant to wind gusts. The screens may unroll or roll up at different speeds if there is a
combination of different systems, single or coupled systems, or systems with different dimensions.
At the outside, polyester blackout fabric can only be used under the dimensions and with the products as described in the technical documentation.
The ZipShade Medium Slim F & ZipShade
®
* Converted for your convenience. Rounding errors may occur, certificate is based on tests in km/h.
Medium Slim (F) / ZipShade Large (F)
®
120 Volt AC - 60Hz
0,95 to 2.1 Amps (depends on motor type)
110 to 250 Watt (depends on motor type)
approx. 5 minutes
Medium Slim (F) / ZipShade Large (F) are conform wind class 3,
®
Product not tested/not in compliance
4 bft
5 bft
6 bft
Large F can only be used under the dimensions as described in the technical documentation.
®
Sunprotection-Screens
RENSON ZipShade
Sunprotection-Screens.
®
Rating
IP 44
Wind speed
20 - 27 km/h
28 - 37 km/h
38 - 48 km/h
(F)
®
Wind speed (mph*)
≈ 13 - 17 mph
≈ 18 - 24 mph
≈ 25 - 30 mph
1
