1.1 Interface

10
9
8
Item
1
2
3
4
5
6
7
8
9
10
8
7
Figure 1 (MR525 shown)
Fixed (non-mobile) jaw
Banana plugs (4mm)
Arrow indicating current flow direction
DC Zero button
OL (overload) and ON indicators. ON is green when Auto
Standby is enabled, yellow when it disabled.
Slide switch (2-position for MR525, 3-position for MR526)
USB port
Trigger
Hand guard
Mobile jaw
1
2
Function
Current Probe Models MR525/526
3
4
5
6
