Maintenance

The CiNX Fluid head offers high quality surface coatings, dust
and moisture seals. Miller recommends keeping the Fluid head
clean at all times by using soft brushes and lint free cloth to wipe
over the surfaces.
• Do not immerse the Fluid head in any liquid.
• Do not use stiff brushes, abrasives, harsh detergents and
solvents.

Battery Replacement

The CiNX Fluid head uses a single GP23A type - 12 Volt battery
for Illumination. Miller recommends the following batteries to
provide long life performance – Duracell MN21/23, Eveready A23
or Vinnic L1028.
• Using a Phillips head #1 screw driver, remove the two
RETAINING SCREWs, BATTERY DOOR and the old battery.
• Insert the new battery as shown in (Fig. 12).
• Insert the tab on the BATTERY DOOR into the body first then
align the two screw holes and tighten the screws snugly.
12 12
Illumination Button
Battery Battery Door Retaining Screw
Fig. 12
