Call Settings - BAS-IP AV-01KD Manual

Enable/Disable: Enable/disable SIP registration.
Proxy: A proxy SIP server that can be represented by both an IP address and a domain name.
Data format:
Before the proxy address, you must specify "sip:".
Server: SIP server address.
Data format:
Сan be represented by both an IP address and a domain name.
STUN IP: STUN server address.
Example:
stun.l.google.com.
STUN port: The port of the STUN server.
Example:
For google STUN server 19302 port is used.
Password: Password of SIP number.
Automatic re-registration: Re-register the device on the SIP server.
Re-registration interval: Input field for the time interval in seconds, after which the device will be
re-registered on the SIP server.

Call settings

Configuration through WEB interface – 11
