AXIS T85 PoE+ Network Switch Series

How to install the product

Mount the product in a rack - AXIS T8508
Below section describes how to mount AXIS T8508 in a rack.
NO NO TICE NO TICE TICE
The switch is not equipped with a fan for cooling, do not cover the switch or block the
airflow.
Note
The mounting brackets used for rack mounting of AXIS T8508 are sold separately.
1. Attach the mounting brackets to both sides of the chassi. Insert screws (3x) and tighten
them with a screwdriver to secure the brackets.
2. Place the product on a rack shelf in the rack. Push it in until the oval holes in the
brackets align with the mounting holes in the rack posts.
3. Attach the brackets to the posts. Insert screws (2x) and tighten them.
