AXIS T85 PoE+ Network Switch Series

Specifications

To find the latest version of the product's datasheet, go to the product page at axis.com and
locate Support & Documentation.

LED indicators

System LED
LED
System
Mode LED
LED
Link/Act/Speed
PoE
By pressing the Mode/Reset button in less than 2 seconds to change LED modes (Link/Act/Speed
Mode or PoE Mode), users can check the port status by reading the LED behaviors in the tables
below.
Color
Green (lit)
N/A
Red (lit)
Color
Green (lit)
Amber (lit)
Green (lit)
16
Indication
The switch is powered ON.
The switch is not receiving
power.
An abnormal state, such
as exceeding operating
temperature range, has been
detected in the switch.
Indication
The RJ45/SFP Port Status LEDs
are displaying link status and
network activity of each port,
with connection speed of
1000Mbps.
The RJ45/SFP Port Status LEDs
are displaying link status and
network activity of each port,
with connection speed of
10/100Mbps.
The RJ45 Port Status LEDs
are displaying PoE powering
status of each port.
