Four-Way Cassette Type
Please check whether the following fittings are of full scope. If there are some attached fittings free
from use, please restore them carefully.
Installation Fittings
1. Expansible hook (x4)
2. Installation hook (x4)
3. Installation paper board (x1)
4. Bolt M5 X 16 or M6 X 12 (x4)
Tubing & Fittings
5. Connecting pipe group (x1)
6. Binding tape (x6)
7. Soundproof / insulation sheath (x2)
Drainpipe Fittings
8. Out-let pipe sheath (x1)
9. Out-let pipe clasp (x1)
10. Tightening band (x20)
11. Drain elbow (x1)
12. Seal ring (x1)
Protect Pipe Fittings
13. Wall conduit (x1)
14.Wall conduit cover (x1)
Remote controller & Its Frame
15. Remote controller (x1)
16.Frame (x1)
17.Mounting screw (ST2.9 x 10-C-H) (x2)
18. Alkaline dry batteries (AM4) (x2)
Others
19. Owner's manual (x1)
20. Installation manual (x1)
