RESTORING THE FACTORY DEFAULT SETTINGS

4 RESTORING THE FACTORY DEFAULT SETTINGS
In case you want to restore the factory default settings remove the power supply cable, press
and hold the Set button (1) with a sharp pin and plug in the power supply cable (2) (see pic-
ture below).
10/100 Base-T PLANET PORT 1 PORT 2 13,2VDC IN
max. 1A
PWR
LINK OK
SET
TX/RX STATUS
PLANMECA ETHERNET INTERFACE
2
1
Installation manual Planmeca Ethernet interface 13
