INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE PLANMECA PROLINE XC X-RAY
The following window appears. Change your client name, Ethernet Interface IP address, Eth-
ernet Interface port and Proline box port number. Confirm your selection by clicking " save " on
the File pull-down menu.
If a password has been set, it must include only capital letters. Do not use space or special
characters.
Client name
Computer name
"Localhost"
Ethernet Interface
IP Address
OR
Network Name
The Planmeca Ethernet Interface is now installed and you can enter the Dimaxis Pro or
Dimaxis Classic program.
NOTE Before installing the device to the network contact your network administrator
if needed.
12 Planmeca Ethernet interface
/PASSWD
Proline Port
Ethernet Interface
IP Port
Password
