Planmeca Ethernet Interface Installation Manual page 11

INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE DIXI3 DIGITAL INTRA X-RAY
The following window appears. Change your client name, Ethernet Interface IP address, Eth-
ernet Interface port and Dixi2 port number. Confirm your selection by clicking " save " on the
File pull-down menu.
If a password has been set, it must include only capital letters. Do not use space or special
characters.
Client name
Computer name
"Localhost"
The Planmeca Ethernet Interface is now installed and you can enter the Dimaxis Pro or
Dimaxis Classic program.
NOTE Before installing the device to the network contact your network administrator
if needed.
Installation manual
Ethernet Interface
IP Port
Ethernet Interface
IP Address
OR
Network Name
PASSWD
Dixi2 Port
Password
Planmeca Ethernet interface 7
