- Page 1 EMB-7535 USER' Manual V1.0...
- Page 2 EMB-7535 USER' Manual V1.0 SZ HQ: 0755-27331166 Beijing Office: 010-82671166 Shanghai Office: 021-61212081 Chengdu Office: 028-85259319 Shenyang Office: 024-23960846 Xi’an Office: 029-88338386 Nanjing Office: 025-58015489 Wuhan Office: 027-87858983 Tianjin Office: 022-23727100 Singapore: 65-68530809 For more information, please visit：www.norco.com.cn...
- Page 3 Shenzhen NORCO Intelligent Technology Co.,Ltd. EMB-7535 Digital Signage Special Board Shenzhen NORCO Intelligent Technology Co.,Ltd. Place/Date: HONG KONG/2019...
- Page 4 Trade Name： Shenzhen NORCO Intelligent Technology Co.,Ltd. Model Name：EMB-7535 Responsible Party： Shenzhen NORCO Intelligent Technology Co.,Ltd. Equipment Classification：FCC Class B Subassembly Type of Product：EMB-7535 Digital Signage Special Board Manufacturer： Shenzhen NORCO Intelligent Technology Co.,Ltd. Date: 2019...
- Page 5 Before buying products, please learn about the product performance from the distributors to see if it is in line with your needs. NORCO is a registered trademark of Shenzhen NORCO Intelligent Technology CO., LTD.
- Page 6 Safety Instructions 1. Before using this product, please read this user’s manual carefully; 2. Any plate cards not ready to be installed shall be kept in the anti-static protective bags; 3.Before taking out the plate cards from the anti-static protective bags, first place hands on the grounding metal object for a while so as to release the static electricity from your body and hands;...
-
Page 7: Table Of Contents
Content Chapter One Product Introduction....................1 1.1 Hardware Specification........................1 Chapter Two Hardware Function.......................3 2.1 Interface Location and Dimension Diagram...................3 2.2 Installation Steps..........................3 2.3 Jumper Setting...........................4 2.4 Interface Specification........................4 2.4.1 Serial Port（COM_DB）........................4 2.4.2 USB Port（USB，OTG）....................5 2.4.3 Ethernet Interface（J7）........................6 2.4.4 Audio Interface（HP， MIC， AMP） ....................7 2.4.5 Display Port（J2，EDP，J5）.................. - Page 8 Appendix..............................22 Appendix 1：Glossary........................22...
- Page 9 Packing List Thanks for purchasing NORCO products. Please check the accessories as per the packing list when you open the package. If you find any components/parts defected, damaged or lost, please contact your vendor ASAP. ■ EMB-7535 motherboard...
- Page 10 Chapter Product Introdu ction...
-
Page 11: Chapter One Product Introduction
EMB-7535 User’s Manual Chapter One Product Introduction 1.1 Hardware Specification Size ●Size：78mmX106mm Processor ●CPU：RK3399，hexa core (dual core A72 2GHz + quad core A53 1.5GHz) System Memory ●On board memory：Support LPDDR3，memory up to 4G Bytes，default 2GB Display ●Display port：HDMI，eDP ●HDMI：resolution up to：4Kx2K @60fps output，port:FPC/0.5MM/24P ●eDP：1x eDP，port:FPC/0.5MM/24P... - Page 12 EMB-7535 User’s Manual ●Serial port： Provide 3x serial ports， 2x UART ports； 1x RS232 debug port； and ESD protection ●USB： Provide 3x standard USB port， in which 1x OTG port， used for programming； 1x USB3.0 port；1x USB2.0 port；and ESD protection MIPI CSI（camera）...
- Page 13 Chapter Hardware Function...
-
Page 14: Chapter Two Hardware Function
EMB-7535 User’s Manual Chapter Two Hardware Function 2.1 Interfaces Location and Dimension Following picture illustrates the front interfaces and dimension of board EMB-7535. Please pay attention to the installation process. Improper installation of some components may lead to system failure. -
Page 15: Jumper Setting
EMB-7535 User’s Manual 3．Connect all signal line, cables, panel control circuit and power adapter. Key components of this motherboard are Integrated circuit and these components could be easily damaged by electrostatic influence. So, before installing this unit, please always keep the following precautions in mind：... -
Page 16: Usb Port（Usb，Otg
EMB-7535 User’s Manual COM_DB COM_DB： Signal Name COM2_TXD COM2_RXD 2.4.2 USB Port（USB，OTG） Provide 1x OTG （ Micro USB port ， support Host and Device mode ， for system programming； 1 x USB3.0 (TYPE A horizontal) port. - Page 17 EMB-7535 User’s Manual 2.4.3 Ethernet（J7） Provide 1 x 1000M Ethernet interface （PH1.25/12P slot） ， external interface board. ,RJ45 network interface, Yellow indicates data transmission status, Green indicates network connection status.
-
Page 18: Audio Interface（Hp，Mic，Amp
EMB-7535 User’s Manual RJ45 LAN LED State Description： LILED（Green） Function ACTLED （Yellow） Function 100/1000M link FLASH Data transfer 10M link or closed Data transfer stop J7： Signal Name Signal Name LAN_TXD3_N LAN_TXD3_P LAN_TXD2_N LAN_TXD2_P LAN_TXD1_N LAN_TXD1_P LAN_TXD0_N LAN_TXD0_P LED_ACT LED_LINK 3.3V... - Page 19 EMB-7535 User’s Manual HP： Signal Name HeadPh_R HeadPh_L HEADPHONE_DET MIC： Signal Name MIC_IN1R MIC_IN1L AMP： Signal Name OUTPL OUTNL...
-
Page 20: Display Port（J2，Edp，J5
EMB-7535 User’s Manual OUTNR OUTPR 2.4.5 Display Port（J2，EDP，J5） Provide 1 x HDMI display port （FPC0.5M/24P FPC connector） ， external interface board； 1x eD port （ FPC0.5M/30P FPC connector ） ， 1x eDP switch 5V/12V power supply jumper interface. J2： Signal Name... - Page 21 EMB-7535 User’s Manual HDMI_TX0N HDMI_TX0P HDMI_TX1N HDMI_TX1P HDMI_TX2N HDMI_TX2P J5： Signal Name DCIN VCC_LCD VCC5 EDP： Signal Name Signal Name VCC_LCD VCC_LCD VCC_LCD 3.3V I2C3_SDA_TP I2C3_SCL_TP EDP_EN TP_INT EDP_BL_EN EDP_BL_PWM EDP_RST TP_RST EDP_TX3P EDP_TX3N EDP_TX2P EDP_TX2N EDP_TX1P EDP_TX1N EDP_TX0P EDP_TX0N...
-
Page 22: Power Interface（Pwr，J4
EMB-7535 User’s Manual 2.4.6 Power Interface（ PWR，J4 ） PWR： Signal Name +12V J4： Signal Name Signal Name RESET_USB HOST1_DP HOST1_DM +12V +12V +12V 2.4.7 Camera Interface (CAM） Provide 1 x MIPI camera interface（FPC0.5M/30P FPC connector）. - Page 23 EMB-7535 User’s Manual CAM： Signal Name Signal Name MIPI_RX0_D0N MIPI_RX0_D0P MIPI_RX0_CLKN MIPI_RX0_CLKP MIPI_RX0_D1N MIPI_RX0_D1P MIPI_RX0_D2N MIPI_RX0_D2P MIPI_RX0_D3N MIPI_RX0_D3P MIPI_MCLK0 MIPI_PWDN MIPI_RST_N I2C1_SCL I2C1_SDA VCC_2V8_DVP VCC5 VCCA1V8_DVP VCC_1V2_CAM VCC_2V8_DVP VCCA1V8_DVP...
-
Page 24: Touch Screen Interface（Touch
EMB-7535 User’s Manual 2.4.8 Touch Screen Interface（TOUCH） Provide 1x touch screen interface（PH1.25/6P slot）. TOUCH TOUCH： Signal Name Signal Name +3.3V I2C4_SDA_TOUCH I2C4_SCL_TOUC TOUCH_RST_N TOUCH_INT... -
Page 25: Fan Interface（J3
EMB-7535 User’s Manual 2.4.9 Key（RECOVER，PWR_KEY，RST_KEY） Provide 3x keys：RECOVER、PWR_KEY、RST_KEY. RECOVER PWR_KEY RST_KEY 2.4.10 Fan Interface（J3） Provide 1x fan interface（PH1.25/2P slot），voltage: 5V（12V optional）. -
Page 26: Expansion Interface（J1
EMB-7535 User’s Manual Signal Name VCC_FAN 2.4.11 Expansion Interface（J1） Provide 1x expansion interface（PH1.25/16P slot）. - Page 27 EMB-7535 User’s Manual J1： Signal Name Signal Name 1.8V MINIPCIE_RST MINIPCIE_DISABLE 3G_WAKEUP EC20_WAKEUP_OUT EC20_WAKEUP_IN COM4_RX COM4_TX UART0_TXD_1V8 UART0_RXD_1V8 WG_GPIO2 WG_GPIO1 GPIO2_C2 WLED_CTL GLED_CTL RLED_CTL...
- Page 28 Chapter Three Software Function...
-
Page 29: Chapter Three Software Function
EMB-7535 User’s Manual Chapter Three Software Function 3.1 Android System 3.1.1 Display Support edp and HDMI port single output Support edp and HDMI port duplicate output at the same time Support edp and HDMI port simultaneous asynchronous output edp port，the driver should be customized according to the actual use of LCD screen. -
Page 30: Sound Card
EMB-7535 User’s Manual 3.1.9 Sound Card Support local sound card and HDMI dual channel sound card. Local sound card support a pair of independent headphone, and MIC. 3.1.10 Camera Support USB camera and mipi camera. 3.1.11 Wiegand Output Support 1x Wiegand output. - Page 31 Appen...
- Page 32 EMB-7535 User’s Manual Appendix Appendix 1：Glossary BUS is a channel for different devices to exchange data in computer system. It is hardware circuit. BUS here refers to partial lines inside CPU and the main components of system memory. Chipset Chipset is an Integrated set of chips for executing one or more related functions。Here it refers to a system level chipset structured by South bridge &...
- Page 33 EMB-7535 User’s Manual communications links. Terminals can access data and devices anywhere through cables, which enables users to share costly devices and resource. Light-Emitting Diode. A semiconductor device that lighted when power supply is connected, It is often used to indicate information directly, for example, to indicate power on or HDD working normally.
