  • Page 1 EMB-7570 V1.0...
  • Page 2 EMB-7570 V1.0 SZ HQ: 0755-27331166 Beijing Office: 010-82671166 Shanghai Office: 021-61212081 Chengdu Office: 028-85259319 Shenyang Office: 024-23960846 Xi’an Office: 029-88338386 Nanjing Office: 025-58015489 Wuhan Office: 027-87858983 Tianjin Office: 022-23727100 Singapore: 65-68530809 For more information, please visit：www.norco.com.cn...
  • Page 3 Before buying products, please learn about the product performance from the distributors to see if it is in line with your needs. NORCO is a registered trademark of Shenzhen NORCO Intelligent Technology CO., LTD.
  • Page 4 Safety Instructions 1. Before using this product, please read this user’s manual carefully; 2.Any plate cards not ready to be installed shall be kept in the anti-static protective bags; 3.Before taking out the plate cards from the anti-static protective bags, first place hands on the grounding metal object for a while so as to release the static electricity from your body and hands;...

  • Page 5: Table Of Contents

    Content Chapter One Product Introduction ....................1 1.1 Hardware Specification......................1 Chapter Two Hardware Function ...................... 3 2.1 Interface Location and Dimension Diagram..............- 3 - 2.2 Installation Steps........................- 4 - 2.3 Jumper Setting........................- 4 - 2.3.1 COM1 Jumper Setting（J1，J2）................. - 4 - 2.4 Interface Specification......................
  • Page 6 3.1.2 HDMI..........................22 3.1.3 LCD..........................22 3.1.4 USB..........................22 3.1.5 COM..........................23 3.1.6 TF Card......................... 23 3.1.7 CAN..........................23 3.1.8 Ethernet......................... 23 3.1.9 Sound Card and Microphone..................23 3.1.10 Camera........................24 Appendix ..............................26 Appendix 1：Glossary........................26...
  • Page 7 Packing List Thanks for purchasing NORCO products. Please check the accessories as per the packing list when you open the package. If you find any components/parts defected, damaged or lost, please contact your vendor ASAP. ■ EMB-7570 V1.0 motherboard...
  • Page 8 Chapter Product Introdu ction...

  • Page 9: Chapter One Product Introduction

    EMB-7570 V1.0 Chapter One Product Introduction 1.1 Hardware Specification Size ●Size：170mmX120mm Processor ●CPU：IMX8QMAX ，hexa core (2*A72+4*A53 1.6GHz) System Memory ●On board memory，support LPDDR4，memory up to 8G Bytes，default 6GB Display ●Display port：HDMI，LVDS，MIPI DSI ●HDMI：Provide 1x HDMI resolution: 4K@60HZ ●LVDS：Provide 2x LVDS resolution:1080p@60HZ ●MIPI DSI ：Provide 2x MIPI DSI resolution:4K@60HZ...
  • Page 10 EMB-7570 V1.0 ●Serial ports：3x RS232，1 x RS485/RS232，1 x COM_DB ●USB：5 x USB ports；in which 4 x USB2.0,1 x OTG port；1 x USB 3.0 Expansion Port ●Provide 1 x MINI PCIe slot，support Mini-PCIE/3G/4G /WLAN optional ●Provide 1 x SIM card slot；support 3G/4G module ●Provide 1 x SD card slot...
  • Page 11 Chapter Hardware Function...

  • Page 12: Chapter Two Hardware Function

    EMB-7570 V1.0 Chapter Two Hardware Function 2.1 Interfaces Location and Dimension Following picture illustrates the front interfaces and dimension of board EMB-7570 V1.0. Please pay attention to the installation process. Improper installation of some components may lead to system failure.

  • Page 13: Installation Steps

    EMB-7570 V1.0 2.2 Installation Steps Please follow the steps below to assemble your computer： 1．Adjust all jumpers on-board EMB-7570 V1.0 according to the user manual 2．Install other expansion cards 3．Connect all signal line, cables, panel control circuit and power adapter.

  • Page 14: Interface Specification

    EMB-7570 V1.0 transmission mode， you can choose settings according to your own needs， default transmission mode: RS232. Up J2，Down J1 COM1 AS RS232 PORT COM1 AS RS485 PORT 3-4 5-6 1-3 2-4 3-5 4-6 2.4 Interface Specification Please read this manual carefully before connecting the external connector to avoid damage to the motherboard！...

  • Page 15: Serial Port（Com_Db，Com1_2，Com3_4

    EMB-7570 V1.0 SATA_PWR SATA SATA_PWR： Signal Name VCC_PER_3V3 VCC_PER_5V0 2.4.2 Serial Port（COM_DB，COM1_2，COM3_4） Provide 3x RS232，1x RS485/RS232，1x COM_DB.

  • Page 16: Usb、Lan Port（Usb3，Usb_Lan1，Usb_Lan2，Otg)

    EMB-7570 V1.0 COM_DB COM3_4 COM1_2 COM_DB： Signal Name Signal Name M40_RXD COM0_RXD M40_TXD COM0_TXD 2.4.3 USB、LAN Port（USB3，USB_LAN1，USB_LAN2，OTG) Provide 5x USB port ； In which 4x USB2.0 ，1x OTG port ； 1x USB 3.0. and 2x RJ45 network interface， Yellow for data transmission status, and green for network connection status.
  • Page 17 EMB-7570 V1.0 USB_LAN2 USB_LAN1 USB3 RJ45 LAN LED Status Description： LILED（Green） Function ACTLED（Yellow） Function 100/1000M link FLASH Data transfer 10M link or closed Data transfer stop 2.4.4 Display Port（HDMI_OUT，HDMI_IN，LVDS1，LVDS2，J3，J4，JLVDS1， JLVDS2） Provide 1x HDMI display port. 2x LVDS port；2x JLVDS backlight interface. 2x MIPI DSI...
  • Page 18 EMB-7570 V1.0 Left LVDS1，Right JLVDS2 JLVDS2 JLVDS1...
  • Page 19 EMB-7570 V1.0 Left J3，Right J4 HDMI_IN HDMI_OUT LVDS1： Signal Name Signal Name LVDS_VDD1 LVDS_VDD1 LVDS_VDD1 LVDS0_EN LVDS0_CH0_TX0_N LVDS0_CH0_TX0_P LVDS0_CH0_TX1_N LVDS0_ CH0_TX1_P LVDS0_CH0_TX2_N LVDS0_ CH0_TX2_P LVDS0_ CH0_CLK_N LVDS0_CH0_CLK_P LVDS0_CH0_TX3_N LVDS0_CH0_TX3_P LVDS0_CH1_TX0_N LVDS0_ CH1_TX0_P LVDS0_CH1_TX1_N LVDS0_ CH1_TX1_P LVDS0_CH1_TX2_N LVDS0_ CH1_TX2_P LVDS0_ CH1_CLK_N...
  • Page 20 EMB-7570 V1.0 LVDS0_CH1_TX3_N VDS0_ CH1_TX3_P LVDS2： Signal Name Signal Name LVDS_VDD2 LVDS_VDD2 LVDS_VDD2 LVDS1_EN LVDS1_CH0_TX0_N LVDS1_CH0_TX0_P LVDS1_CH0_TX1_N LVDS1_CH0_TX1_P LVDS1_CH0_TX2_N LVDS1_CH0_TX2_P LVDS1_CH0_CLK_N LVDS1_CH0_CLK_P LVDS1_CH0_TX3_N LVDS1_CH0_TX3_P LVDS1_CH1_TX0_P LVDS1_CH1_TX0_N LVDS1_CH1_TX1_P LVDS1_CH1_TX1_N LVDS1_CH1_TX2_P LVDS1_CH1_TX2_N LVDS1_CH1_CLK_N LVDS1_CH1_CLK_P LVDS1_CH1_TX3_N LVDS1_CH1_TX3_P JLVDS1： Signal Name LCD0_PWM LCD0_EN 12VDC_OUT1 12VDC_OUT1 JLVDS2：...
  • Page 21 EMB-7570 V1.0 LCD1_PWM LCD1_EN 12VDC_OUT2 12VDC_OUT2 J3（MIPI DSI Port）： Signal Name Signal Name MIPI_DSI1_CLK_N MIPI_DSI1_DATA0_N MIPI_DSI1_CLK_P MIPI_DSI1_DATA0_P VCC_PER_1V8 MIPI_DSI1_DATA1_N VCC_PER_1V8 MIPI_DSI1_DATA1_P VCC_12V MIPI_DSI1_BL_PWM VCC_12V MIPI_DSI1_TS_INT_B MIPI_DSI1_TS_SDA MIPI_DSI0_1_EN MIPI_DSI1_TS_SCL VCC_PER_3V3 MIPI_DSI1_DATA2_N VCC_PER_3V3 MIPI_DSI1_DATA2_P VCC_PER_5V0 MIPI_DSI1_DATA3_N VCC_PER_5V0 MIPI_DSI1_DATA3_P J4（MIPI DSI Port）： Signal Name...
  • Page 22 EMB-7570 V1.0 VCC_PER_1V8 MIPI_DSI0_DATA1_N VCC_PER_1V8 MIPI_DSI0_DATA1_P VCC_12V MIPI_DSI0_BL_PWM VCC_12V MIPI_DSI0_TS_INT_B MIPI_DSI0_TS_SDA MIPI_DSI0_1_EN MIPI_DSI0_TS_SCL VCC_PER_3V3 MIPI_DSI0_DATA2_N VCC_PER_3V3 MIPI_DSI0_DATA2_P VCC_PER_5V0 MIPI_DSI0_DATA3_N VCC_PER_5V0 MIPI_DSI0_DATA3_P...

  • Page 23: Lvds Powerjumper Setting（J10，J11

    EMB-7570 V1.0 2.4.5 LVDS Power Jumper Setting（J10，J11） LVDS1_VPANEL=3.3V LVDS1_VPANEL=5V LVDS1_VPANEL=12V LVDS2_VPANEL=3.3V LVDS2_VPANEL=5V LVDS2_VPANEL=12V 2.4.6 Audio Port（HP） On board 1x MIC IN，1x Headphone output，1x Line-out，5W power amplifier...
  • Page 24 EMB-7570 V1.0 HP: International standard interface definition of standard four section headphone...

  • Page 25: Power Amplifier Interface（Spk

    EMB-7570 V1.0 2.4.7 Power Amplifier Interface（SPK） SPK： Signal Name OUTPL OUTNL OUTpL OUTnL...

  • Page 26: Imx8 Sim Port（J5

    EMB-7570 V1.0 2.4.8 imx8 SIM Port（J5） J5： Signal Name Signal Name VCC_SIM SIM_CLK SIM_RST SIM_IO SIM_PD...

  • Page 27: I2C Touch Screen Interface（J6

    EMB-7570 V1.0 2.4.9 I2C Touch Screen Interface（J6） J6： Signal Name Signal Name VCC_PER_3V3 VCC_PER_3V3 LVDS0_TS_INT33 LVDS1_TS_INT33 LVDS0_SDA_33 LVDS1_SDA_33 LVDS0_SCL_33 LVDS1_SCL_33...

  • Page 28: Qspi Port（J7

    EMB-7570 V1.0 2.4.10 QSPI Port（J7） J7： Signal Name Signal Name VCC_1V8 QSPI0A_CLK QSPI0_DAT0 QSPI0A_CS_B QSPI0_DAT1 QSPI0_DQS QSPI0_DAT2 QSPI0B_CLK QSPI0_DAT3 QSPI0B_CS_B QSPI0_DAT4 QSPI0A_SS1_B QSPI0_DAT5 QSPI0A_SATA1 QSPI0_DAT6 QSPI0A_DATA2 QSPI0_DAT7 QSPI0A_DATA3 QSPI_POR_B_1V8...

  • Page 29: Programmable I / O Port（J8

    EMB-7570 V1.0 2.4.11 Programmable I / O Port（J8） J8： Signal Name Signal Name VCC_PER_1V8 VCC_PER_3V3 ESAI0_MCLK MCLK_IN0 ESAI0_SCKT SPDIF0_EXT_CLK ESAI0_SCKR MCLKIN1(SPDIF0_RX) ESAI0_FST MCLKOUT1(SPDIF0_TX) ESAI0_FSR ESAI1_SCKT ESAI0_TX0 ESAI1_SCKR ESAI0_TX1 ESAI1_FST ESAI0_TX2_RX3 ESAI1_FSR ESAI0_TX3_RX2 ESAI1_TX0 ESAI0_TX4_RX1 ESAI1_TX1 ESAI0_TX5_RX0 ESAI1_TX2 MLB_DATA_P ESAI1_TX3...

  • Page 30: Spi、I2C、Adc Port（J9

    EMB-7570 V1.0 MLB_DATA_N ESAI1_RX1 ESAI1_RX0 MLB_CLK_N PER_RST_B_1V8 MLB_CLK_P MLB_DATA MLB_CLK MLB_SIG_N MLB_SIG MLB_SIG_P MLB_INT_B(USDHC1_STR0BE) 2.4.12 SPI、I2C、ADC Port（J9） J9： Signal Name Signal Name VCC_PER_1V8 VCC_PER_3V3 GPT1_CLK TAMPER_IN0 TAMPER_OUT0 SPI3_MISO TAMPER_IN1 SPI3_SCLK TAMPER_OUT1 SPI3_MOSI...
  • Page 31 EMB-7570 V1.0 SPI3_CS0 SPI3_CS1 M41_I2C0_SCL M41_I2C0_SDA SPI2_MISO I2C4_3V3_SCL SPI2_MOSI I2C4_3V3_SDA SPI2_SCLK I2C0_3V3_SCL SPI2_CS0 I2C0_3V3_SDA GPIO3_18(ADC_IN0) SPI0_MISO SPI3_INT(ADC_IN1) SPI0_SCLK GPIO3_20(ADC_IN2) SPI0_MOSI SPI1_CLK(ADC_IN3) SPI0_CS0 SPI1_SDO(ADC_IN4) SPI1_SDI(ADC_IN5) SCU_GPIO0_08 SPI1_CS0(ADC_IN6) SCU_GPIO0_05 SPI1_CS1(ADC_IN7)

  • Page 32: Reset And Power Key（Pwrsw，Rstsw

    EMB-7570 V1.0 2.4.13 Reset and Power Key（PWRSW，RSTSW） Up RSTSW（Reset），Down PWRSW （Power） 2.4.14 LED Indicator（LED1，LED2） It supports 2x external LED lights, up is green, down is red, green for operating, red for power...
  • Page 33 EMB-7570 V1.0 Up LED1，Down LED2...

  • Page 34: Cam Port（Cam1，Cam2

    EMB-7570 V1.0 2.4.15 CAM Port（CAM1，CAM2） Up CAM2，Down CAM1 CAM1-2： Signal Name Signal Name DATA0_N DATA0_P CLK_N CLK_P DATA1_N DATA1_P DATA2_N DATA2_P DATA3_N DATA3_P MCLK_OUT RST_B I2C0_SCL I2C0_SDA VCC_2V8_CAM...

  • Page 35: Can Port

    EMB-7570 V1.0 VCC_PER_5V0 VCC_PER_1V8 VCC_1V2_CAM VCC_2V8_CAM VCC_PER_1V8 2.4.16 CAN Port CAN： Signal Name Signal Name VCC_PER_5V0 VCC_PER_5V0 CAN0_H CAN0_L CAN1_H CAN1_L CAN2_H CAN2_L 2.4.17 Port（TF） Provide 1x TF card port...
  • Page 36 EMB-7570 V1.0 TF card port...

  • Page 37: Pcie Port

    EMB-7570 V1.0 2.4.18 Power Interface（ PWR，J16，J21） J16+J21 PWR： Signal Name J16+J21： Signal Name 2.4.19 PCIe Port Board with 1x PCIeX1 slot，users can expand 3G / 4G devices according to their own needs...
  • Page 38 EMB-7570 V1.0 Chapter Three Software Function...

  • Page 39: Chapter Three Software Function

    EMB-7570 V1.0 Chapter Three Software Function 3.1 Linux 4.9.37 System 3.1.1 mpp sample introduction For the specific usage of these samples, please refer to the company's wiki website. If there is no special description, all the following commands are entered in the serial port terminal.

  • Page 40: Hdmi

    EMB-7570 V1.0 3.1.1.21 vo_screen_dump Sample of dump output screen image data 3.1.1.22 vo_wbc_dump Sample of output image data dump of write back device 3.1.1.23 vpss_chn_dump Sample of the user obtains Cnt frames from the channel and completes image dump 3.1.1.24 vpss_src_dump Sample of dump video buffer pool frame data 3.1.2 HDMI...

  • Page 41: Com

    EMB-7570 V1.0 3.1.5 COM Serial port operation node：ttyLP0 ttyLP1 ttyLP2 ttyLP3 Instructions: Connect serial port 2 ~ 5 to the circuit busybox cp -rf com_arm/ /data/ cd /data/com_arm/ Input ./c_android.sh Input baud rate and test time according to program prompts Automatic display of test results after program running 3.1.6 TF Card...

  • Page 42: Camera

    EMB-7570 V1.0 You can also play the audio or video file test sound card in the Android interface. 3.1.10 Camera Support UVC camera, MIPI/CSI camera...

  • Page 43: Appendix

    Appen...

  • Page 44: Appendix 1：Glossary

    EMB-757 V1.0 Appendix Appendix 1：Glossary ACPI Advanced Configuration and Power Management. ACPI specifications allow operating system to control most power of the computer and its add-on. Windows 98/98SE，Windows 2000 and Windows ME supports this specification. BIOS Basic input/output system. It is software including all in/out control code interface in PC. The software will detect hardware when it auto boot, operate OS, and provide an interface between OS and hardware.
  • Page 45 EMB-757 V1.0 DIMM Dual-Inline-Memory-Modules. It is a small circuit board with memory chipset providing 64 bit memory bus width. DRAM Dynamic Random Access Memory. It is a general type of memory for regular computer which usually store 1 bit with a transistor and a capacitance. With the development of the technology, more and more types of DRAM with different specifications exist in computer applications.
  • Page 46 EMB-757 V1.0 interface with only 6PIN; it also can connect other devices, like modem. It is the Universal Serial Bus for short. A hardware interface adapts to low speed peripherals, and is always used to connect keyboard, mouse etc. One PC can connect maximum 127 USB devices, providing 12Mbit/s transmit bandwidth USB supports hot swap and multi- data stream, namely, you can plug USB devices while system is running, system can auto-detect and makes it work on.
