Summary of Contents for Norco BIS-6660C

  • Page 1 BIS-6660C USER Manual V1.0...
  • Page 2 BIS-6660C USER Manual V1.0 Shenzhen Headquarters: 0755-27331166 Beijing: 010-82671166 Shanghai: 021-61212081 Chengdu: 028-85259319 Shenyang: 024-23960846 Xi’an 029-88338386 Nanjing: 025-58015489 Wuhan: 027-87858983 Tianjin: 022-23727100 Singapore: 65-68530809 For more information, please visit www.norco-group.com...
  • Page 3 Shenzhen NORCO Intelligent Technology Co.,Ltd. BIS-6660C Network Digital Signage Platform Shenzhen NORCO Intelligent Technology Co.,Ltd. Place/Date: HONG KONG/2011...
  • Page 4 Trade Name： Shenzhen NORCO Intelligent Technology Co.,Ltd. Model Name：BIS-6660C Responsible Party： Shenzhen NORCO Intelligent Technology Co., Ltd. Equipment Classification：FCC Class B Subassembly Type of Product：BIS-6660C Network Digital Signage Platform Manufacturer： Shenzhen NORCO Intelligent Technology Co.,Ltd. Date: 2014...
  • Page 5 Before ordering products, please learn about the product performance from the distributors to see if it is in line with your needs. NORCO is a registered trademark of Shenzhen NORCO Intelligent Technology CO.,LTD. The ownership of other trademarks involved in this manual is owned by its respective owners.

  • Page 6: Safety Instructions

    Safety Instructions 1. Please read this manual carefully before using the product. 2. To prevent electronic shock hazard or any damage to the product, please ensure that all power cables for the devices are unplugged when adding or removing devices or reconfiguring the system. 3.

  • Page 7: Table Of Contents

    Table of Contents Chapter 1 Product Introduction ....................1     1.1Overview ........................1   1.2 Specification ........................1 Chapter 2 Installation Instructions ....................3     Safety Precautions ......................3   2.1Remove the Computer Cover ..................5   2.2 Install Motherboard ....................... 5  ...
  • Page 8   3.3.6 MINI PCIe Socket（MINI PCIe1, MINI PCIe2, J10, J11） ....... 23 Chapter 4 BIOS SETUP ......................24     AMI BIOS FLASH ...................... 24   AMI BIOS Description ....................24   BIOS Setting ......................24   3.1 Main Menu ........................25  ...

  • Page 9: Packing List

    Packing List Thanks for purchasing NORCO products. Please check your package carefully according to the checklist below. If you find any components lost or damaged, please contact your retailer. ■ BIS-6660C 1pcs ■ DC12V 5A Power Adapter 1pcs ■ Original Power Cord 1pcs ■...

  • Page 10: Chapter 1 Product Introduction

    Chapter 1. Product Introduction...

  • Page 11: Overview

    Chapter 1 Product Introduction 1.1Overview The BIS-6660C is NORCO’s newest generation “ICEFIN” low power embedded industrial computer based on Intel’s Bay Trail platform. The Intel Bay Trail platform utilizes Intel’s latest SOC technology, significantly improving processing ability and cutting power consumption in half.
  • Page 12 BIS-6660C User Manual 6XUSB2.0 2XRS232(DB9), Display 1XVGA, 1XDVI-D, 1XHDMI Cooling Fan less , “ICEFIN” Thermal Design Audio 1XMic-in, 1XLine-out Expansions 2XMini Pcle LED Indicator PWR_LED, HDD_LED System Control Power Switch PS/2 WLAN 1x3G/WiFi SMA antenna（optional） GPIO 2x 5 Pin GPIO...

  • Page 13: Chapter 2 Installation Instructions

    Chapter 2. Installation Instructions...

  • Page 14: Safety Precautions

    BIS-6660C User Manual Chapter 2 Installation Instructions Safety Precautions Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire.
  • Page 15 BIS-6660C User Manual •To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. •Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged. •Do not damage the power cord nor place heavy objects on it, stretch it or over bend it.

  • Page 16: Remove The Computer Cover

    BIS-6660C User Manual 2.1Remove the Computer Cover Remove the four screws on cover and dismount the cover 2.2 Install Motherboard 2.2.1 Install Thermal Pad The thermal pad is tailored as per the size of CPU and Chipset and is pressed on to...

  • Page 17: Dismount Rear Panel

    BIS-6660C User Manual 2.2.2 Dismount Rear Panel Loosen four screws on the side of the rear panel and remove rear panel module. 2.2.3 Install the Motherboard Align the semi-circle guide holes of the motherboard with the four guide posts on...

  • Page 18: Mount Rear Panel

    BIS-6660C User Manual 2.2.4 Mount Rear Panel Mount back the rear panel and tighten the four screws on panel 2.3 Install RAM Align the memory bank with the memory slot in the direction of 45 degree and then insert the memory into its socket.

  • Page 19: Install Mini Pcie Devices

    BIS-6660C User Manual 2.4 Install MINI PCIE Devices Remove the screws onboard for fixing the Mini PCIe devices. Then insert the device into the socket at a 45 degree angle. Push against the end of the Mini PCIe device and press it down into the socket, finally tighten the screws.

  • Page 20: Install Hard Disk

    BIS-6660C User Manual 2.5 Install Hard Disk Pull tray upward at a 90 degree angle. Insert the hard disk into the HDD tray. Then close the HDD tray.

  • Page 21: Mount The Top Cover

    BIS-6660C User Manual Use the screwdriver to tighten the four screws on the tray , so as to fix the hard disk. (M3x4mm screws x4PCS) Connect the HDD power cable and data cable to the HDD port and use screws to...

  • Page 22: Rack Dimension

    BIS-6660C User Manual 2.8 Rack Dimension...

  • Page 23: Chapter 3 Hardware Functions

    Chapter 3. Hardware Functions...

  • Page 24: External Interfaces Location

    BIS-6660C User Manual Chapter 3 Hardware Functions 3.1 External Interfaces Location 1：BIS-6660C Rear View 2：BIS-6660C Front View 3.3.1 Serial Ports（COM1, COM2） Board provides 2x serial ports. COM1/ COM2 are standard DB9 serial ports. COM1/2 supports RS232.

  • Page 25: Usb Ports（Usb12, Usb34, Usb56

    BIS-6660C User Manual COM1, COM2: Signal Name 3.3.2 USB Ports（USB12, USB34, USB56） BPC-7940 provides 4x standard double layer USB2.0 ports and one double-layer USB3.0. (USB5 is USB2.0) USB12,USB34, USB56: Signal Name...

  • Page 26: Ethernet Ports（Lan1, Lan2

    BIS-6660C User Manual USB DATA- USB DATA+ 3.3.3 Ethernet Ports（LAN1, LAN2） BPC-7940 provides 2x RJ-45 Gigabit LAN ports. Both sides of the RJ-45 interface has one LED lamp. The yellow one indicates data transfer status. The green one indicates network link status.

  • Page 27: Display Ports（Vga, Dvi-D, Hdmi

    BIS-6660C User Manual 3.3.5 Display Ports（VGA, DVI-D, HDMI） Motherboard BPC-7940 provides one standard 15Pin VGA port to connect VGA display; 1x DVI-D to connect DVI-D display and one 2x10Pin HDMI port. VGA: Signal Name Signal Name Signal Name GREEN BLUE...

  • Page 28: Cmos Clear/Hold Jumper Setting（Jcc

    BIS-6660C User Manual HDMI: Signal Name Signal Name LA_DATA_N0 L_DDC_DATA LA_DATA_P0 L_DDC_CLK LA_DATA_N1 LA_CLK_N LA_DATA_P1 LA_CLK_P LA_DATA_N2 LA_DATA_N3 LA_DATA_P2 LA_DATA_P3 3.3.6 PS/2 System provides standard keyboard and mouse connector, to converted to standard PS/2 keyboard and mouse connector with an adapter cable.
  • Page 29 BIS-6660C User Manual of previous system settings and back to the original system setting (factory default). Steps: （1）Turn off the computer and disconnect the power supply; （2）Use jumper cap short JCC Pin1 and Pin2 for seconds ( Pin1-2) and then restore the default setting with Pin2-3 connected;...

  • Page 30: Auto Boot Upon Power Up（Jat

    BIS-6660C User Manual 3.2.2 Auto Boot upon Power Up（JAT） JAT: Setting Open Disable the auto boot function Close Enable the auto boot function 3.3 Inner Interfaces 3.3.1 SATA Port（SATA） The motherboard provides one standard 7Pin SATA port and one 5Pin SATA power interface.
  • Page 31 BIS-6660C User Manual SATA: Signal Name...

  • Page 32: Power Interface（Dc_Jack

    BIS-6660C User Manual 3.3.3 Power Interface（DC_JACK） DC_JACK: Signal Name +12V 3.3.4 Front Panel Interface（JFP） JFP is used to connect the function buttons and LED lamps on the chassis front panel.
  • Page 33 BIS-6660C User Manual JFP: Signal Name Signal Name POWER LED+ POWER LED- HD LED+ HD LED- BUZZDATA- RESET SW POWER SW Please follow the table below to connect, pay attention to the anode (+) and cathode (-), otherwise, some function cannot be realized.

  • Page 34: So-Dimm Slot

    BIS-6660C User Manual 1）System Power LED Pins（Pin1/2 for PWRLED） Connect system power LED cable with these pins. （ pin 1 is LED anode） When system is power on, power LED is on；when system is power off, power LED is off.

  • Page 35: Chapter 4 Bios Setup

    Chapter 4. BIOS SETUP...

  • Page 36: Ami Bios Flash

    BIS-6660C User Manual Chapter 4 BIOS SETUP AMI BIOS FLASH BIOS functions as a bridge connecting hardware and operating system. Hardware and software are upgrading all the time, so when your system goes wrong, for example, your system can not support the newest CPU, you need to upgrade BIOS to keep up with the latest technology.

  • Page 37: Main Menu

    BIS-6660C User Manual 2. When system pops out the prompt "Press <Del> to enter setup, <F11> to Popup menu”, please press <Del> key to enter BIOS setup interface. 3. Use the “←↑→↓”to select the option which your want to modify, press <Enter> to go to the sub-menu.

  • Page 38: Advanced

    BIS-6660C User Manual System Date System date format: Month (Jan.-Dec.)/Date (01-31)/Year (up to 2099)/Week (Mon.～Sun.). System Time System time format: Hour (00-23)/Minute (00-59)/Second (00-59). 3.2 Advanced Launch LAN1/2 PXE OpROM Enable or disable Boot Option for Legacy Network Devices. ACPI Settings: ACPI sleep mode setting: S1/ S3.

  • Page 39: Acpi Configuration

    BIS-6660C User Manual SATA Configuration: Hard disk mode setting and other info. LPSS&SCC Configuration: OS options. Network Stack Configuration: Load onboard UEFI LAN card boot code or not. CSM Configuration: Compatibility support module control options. USB Configuration: USB information and setting 3.2.1 ACPI Configuration...

  • Page 40: Supper Io Configuration

    BIS-6660C User Manual 3.2.2 Supper IO Configuration Serial Port 1 Configuration Serial Port 2 Configuration Serial Port 3 Configuration Serial Port 4 Configuration Serial Port 5 Configuration Serial Port 6 Configuration Serial Port 7 Configuration Serial Port 8 Configuration Serial Port 9 Configuration...
  • Page 41 BIS-6660C User Manual Serial Port 1 Configuration 1）Serial Port Enable or disable the serial port function. 2）Device Setting（Read Only） This option shows the serial port IRQ and addresses. 3）Change Setting Set serial port IRQ and Address. Serial Port 2-10 Configuration...
  • Page 42 BIS-6660C User Manual WDT Timeout Mode WDT Timeout Mode Select: Minute or Second and it will show the submenu WDT Timeout Value (0-255). System defaults [Disabled].

  • Page 43: H/W Monitor

    BIS-6660C User Manual 3.2.3 H/W Monitor PC Health Status PC Health Status Detect. BIOS will display current system temperature, CPU temperature, FAN rotate speed, and related voltage value.

  • Page 44: Apm Configuration

    BIS-6660C User Manual 3.2.4 APM Configuration RTC Power On Function Enable or Disable System wake on alarm event. When enabled, System will wake on the hr::min::sec specified. RTC Power On Hour To set system wakes on the specific hour. RTC Power On Minute To set system wakes on the specific Minute.

  • Page 45: Serial Port Console Redirection

    BIS-6660C User Manual 3.2.5 Serial Port Console Redirection...
  • Page 46 BIS-6660C User Manual Console Redirection Console Redirection. Board supports COM1 /COM2 console redirection. Default [Disable]. To enable the console redirection is only need to enable COM1 or COM2 console redirection. No need to enable EMS redirection. General Options: 1. Console Redirection 2.

  • Page 47: Cpu Configuration

    BIS-6660C User Manual General Settings: 1. Out-of-Band Mgmt Port: serial port number setting 2. Terminal Type: Terminal types include VT100/VT100+/ VT-UTF8/ANSI. If system gets unreadable code of the terminal console, you need to adjust this option. Default [VT100+]. 3. Bits per second: Baud Rate setting.
  • Page 48 BIS-6660C User Manual The CPUID instruction of some newer CPUs will return a value greater than 3. The default is disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur. To avoid this problem, please enable this field to limit the return value to 3 or lesser than 3.
  • Page 49 BIS-6660C User Manual The read only option contains detailed information of CPU, including CPU manufacturer, model, frequency, L1 Cache, L2 Cache, etc.

  • Page 50: Ppm Configuration

    BIS-6660C User Manual 3.2.7 PPM Configuration EIST Enhanced Intel Speed Step Technology (EIST) is a power and thermal management technology developed by Intel. Enhanced Intel Speed Step Technology allows the system to dynamically adjust processor voltage and core frequency, which can result in decreased average power consumption and decreased average heat production.

  • Page 51: Sata Configuration

    BIS-6660C User Manual 3.2.8 SATA Configuration Serial-ATA Controller(S) Enable or disable the Serial-ATA Controllers. Setting options: [Disabled], [Enhanced], [Compatible]. SATA Speed Support Supported SATA speed SATA Mode Select SATA mode Serial-ATA Port 0 Enable or disable SATA Port0 SATA Port 0 Hotplug...

  • Page 52: Lpcc&Scc Configuration

    BIS-6660C User Manual Serial-ATA Port 1 Enable or disable SATA Port1 SATA Port 1 Hotplug Enable or disable SATA Port1 hot plug 3.2.9 LPCC&SCC Configuration OS Selection: Select OS to install.

  • Page 53: Network Stack Configuration

    BIS-6660C User Manual 3.2.10 Network Stack Configuration UEFI LAN1/2 PXE OpROM Enable or disable UEFI LAN1/2 PXE OpROM. System default [Disable]. Ipv4 PXE Support PXE supports IPV4 Ipv6 PXE Support PXE supports IPV6 PXE boot wait time PXE boot wait time...

  • Page 54: Csm Configuration

    BIS-6660C User Manual 3.2.11 CSM Configuration CSM Support CSM is short for Compatibility Support Module, which is a special module of UEFI, offering compatible support for those systems that unsupport UEFI. GateA20 Active Activate GateA20 Option ROM Messages Optional ROM Messages...

  • Page 55: Usb Configuration

    BIS-6660C User Manual Boot opdtion fildter Network Network Boot Setting Storage Storage Select Video Display Setting Other PCI devices Other PCI devices 3.2.12 USB Configuration Legacy USB Support To support USB device in DOS mode: such as USB Flash Disk, USB keyboard, please select...
  • Page 56 BIS-6660C User Manual <Enabled> or<Auto>. If not, please select < Disabled>. XHCI Support USB3.0 Controller mode select. [Smart Auto]/[Auto] :system is able to auto shift to USB2.0 or USB3.0. [Enable] only support USB3.0. [Disable] will close USB3.0 controller, but unable to shift to USB2.0.

  • Page 57: Chipset Menu

    BIS-6660C User Manual Device Power-up Delay Device Power-up Delay: Set the maximum delay time that USB device takes to report to the master controller. USB Mass Storage Device Set the types of the connected USB devices. [Auto], [floppy], [Forced FDD], [HDD] or CD-ROM.
  • Page 58 BIS-6660C User Manual South Bridge Configuration 3.3.1 North Bridge Integrated Graphics Device Enable: Enable Integrated Graphics Device (IGO) when selected as the Primary video Adaptor. Disable: Always disable IGO Primary Display The primary Display device when system boots. DVMT pre-AIIocated...
  • Page 59 BIS-6660C User Manual 3.3.2 South Bridge Audio Controller Enable or disable the onboard audio controller. Azalia HDMI Codec Enable or disable Azalia HDMI Codec. LAN 1/2 Controller Enable or disable onboard LAN1/2 Controller. Restore AC Power Loss This option is to setup the system status while connecting the power again after the AC Power Loss <Power Off>:System remains the status of power off.

  • Page 60: Boot Menu

    BIS-6660C User Manual 3.4 Boot Menu Setup Prompt Timeout Number of seconds to wait for setup activation key. 60s is the max seconds of timeout. If don’t press Setup activation key within the preset time, system will contiune to start.

  • Page 61: Security Menu

    BIS-6660C User Manual System will detect devices according to the preset sequence until to find a boot device. Option #1 is the prior boot device. Hard Drive BBS Priorities This option contains HDD that can be used as boot device. If multiple HDDs in this option, priority should set for these HDDs, then the prior one will show in Boot Option #1.

  • Page 62: Save & Exit Menu

    BIS-6660C User Manual 3.6 Save & Exit Menu Load Defaults Restore/Load Default values for all the BIOS setup options. Save Changes and Exit Press [Enter] to select this option and press [Enter] to confirm to save all BIOS changes and Exit.

  • Page 63: Appendix

    Appendix...

  • Page 64: Appendix 1: Install Driver

    BIS-6660C User Manual Appendix Appendix 1: Install Driver Please install the driver as per the following steps: Insert the programmed disk into CD-ROM, so installation of the driver can be made either automatically or manually. Now manually installation instructions are given as below: 1) A variety of options are available regarding manually installation, which you can check from Device Manager.

  • Page 65: Appendix 2：Watchdog Programming Guide

    BIS-6660C User Manual Appendix 2：Watchdog Programming Guide watchdog reference code（C） Write data to corresponding ports in C language to realize different functions of Watchdog Timer. Port Instruction: void main() int indexp = 0x4e,datap = 0x4f; unsigned char temp; Outportb(indexp,0x87); Outportb(indexp,0x87); //unlock Outportb(indexp,0x2d);...

  • Page 66: Appendix 3: Glossary

    BIS-6660C User Manual Appendix 3: Glossary ACPI Advanced Configuration and Power Management. ACPI specifications allow O/S to control most power of the computer and its add-ons BIOS Basic input/output system. It is a kind of software including all in/out control code interface in PC.
  • Page 67 BIS-6660C User Manual memory bus width. DRAM Dynamic Random Access Memorizer. It is a normal type of memory often with a transistor and a capacitance to store 1 bit. With the development of the technology, more and more types of DRAM with different specifications exist in computer applications.
  • Page 68 BIS-6660C User Manual It is the Universal Serial Bus for short. A hardware interface adapts to low speed peripherals, and is always used to connect keyboard, mouse etc. One PC can connect maximum 127 USB devices, providing 12Mbit/s transmit bandwidth USB supports hot swap and multi- data stream, namely, you can plug USB devices while system is running, system can auto-detect and makes it work on.
