Page 3
Before ordering products, please learn about the product performance from the distributors to see if it is in line with your needs. NORCO is a registered trademark of Shenzhen NORCO Intelligent Technology CO., LTD. The ownership of other trademarks involved in this manual is owned by its...
Page 4
Safety Instructions 1. Please read the product manual carefully before using this product. 2.Put all the unused or uninstalled boards or electronic components in a static dissipative surface or static shielding bag. 3.Always ground yourself to remove any static discharge before touching the board, to place your hands on grounding metal object for a while or wear an anti-static wrist strap at all times.
VGA+4xCOM output or HDMI+3xUSB output. ●Various Installation Methods BIS-6620 meets VESA MOUNT MIS-D standard. It can be mounted on the back of a device such as a liquid crystal display or placed on a desktop.
BIS-6620 Menlow Platform Based on Mini PC 1.3 Hardware Specification System Model BIS-6620III BIS-6620IV Motherboard BPC-7652+AFC-341V BPC-7652+AFC-450H Intel Atom Z510(1.1GHz FSB400MHz)/Z530(1.6GHz Processor FSB533MHz) Chipset Intel Poulsbo SCH Display HDMI Port Display Controller Intel Poulsbo Integrate GMA500 Video Dynamic sharing 256 MB system memory as display memory Memory Provide 1xSO-DIMM,...
BIS-6620 Menlow Platform Based on Mini PC Environment-Physical Characteristics Operating Temperature -10℃~50℃ Storage Temperature -40℃~60℃ Relative Humidity 5%~95%,non-condensing Vibration Test 0.5g rms/5~500Hz/ Random CE/FCC Class B Dimension 120mm×120mm×40mm (L x W x H) 1.4 Product Dimension Dimension:120mm x 120mm x 40mm(L x W x H)...
BIS-6620 Menlow Platform Based on Mini PC Chapter Two Hardware Function 2.1 External Interface Indicator Diagram 1:BIS-6620 Front view 2:BIS-6620 Rear view BIS-6620III: BIS-6620IV:...
BIS-6620 Menlow Platform Based on Mini PC 2.2 Jumper Setting Please refer to following instructions to do jumper settings before installing your hardware devices. Remark: How to identify the PIN1 of all jumpers and interfaces: Please observe the mark near the plug and socket, which is a “1”...
BIS-6620 Menlow Platform Based on Mini PC compatible USB2.0 specification,support Plug and Play for standard USB devices. If you don't want to use this port, you can disable the USB port in BIOS. 4Pin USB3 port is used to connect optional WIFI wireless network card.
Ms/Kb: Signal Name KB_DATA MS_DATA KB_CLK MS_CLK 2.3.7 Power Port(DC +12V) BIS-6620Ⅰ/Ⅱ with single-supply+12V input. Signal Name +12V 2.4 BIS-6620III Expansion Board Interface 2.4.1 VGA port(VGA) Standard 15Pin VGA port,can connect to all standard VGA interfaces display.
BIS-6620 Menlow Platform Based on Mini PC Signal Name Signal Name Signal Name Green Blue HSYNC VSYNC 2.4.2 Serial Port(COM) Expansion board provides 1xDB44 1 to 4 COM port, When using, it is necessary to use the 1 to 4 COM line in the fittings box to transfer to the standard DB9 COM port.
BIS-6620 Menlow Platform Based on Mini PC DCD5 RXD5 2.5 BIS-6620IV Expansion Board Interface 2.5.1 HDMI Port(HDMI) BIS-6620IV provide 1xHDMI port to connect LCD. Signal Name Signal Name DDC CLK DDC DATA HP DET 2.5.2 SATA Port(SATA) AFC-341V and AFC-450H adaptor plates are both provide with 1x7+15Pin Serial ATA port,...
Page 18
BIS-6620 Menlow Platform Based on Mini PC Signal Name Signal Name +3.3V +3.3V...
3:Prepare a small cross screwdriver 3.1 Remove Host Cover 1:Use cross screwdriver to unscrew four screws at the bottom of BIS-6620. 2:Grasp both sides of the main cover by hand, lift it up and remove it. 3.2 Hardware Installation 3.2.1 Memory module replacement/installation...
BIS-6620 Menlow Platform Based on Mini PC 1:Open host cover. 2:Separate the motherboard from the expansion board and remove it. 3:Choose memory chip that meets motherboard specifications, 4:Align the connecting finger of the memory chip to the groove of the slot of the memory chip, and pay attention to the notch of the connecting finger in the direction of the slot.
3.3 Wall Mounted/ Display Installation BIS-6620 meets VESA MOUNT 100 standard , with installation holes of international standards. It can be mounted directly on the shelf and on the wall. It is convenient to install and...
BIS-6620 Menlow Platform Based on Mini PC fix with LCD and all kinds of objects to save space. 1:Fix the main engine to the wall according to the alignment screw hole position shown in the figure below. 2:Install the main engine behind the display according to the alignment screw hole position shown below.
BIS-6620 Menlow Platform Based on Mini PC Chapter Four BIOS Setup AMI BIOS Refresh BIOS functions as a bridge connecting hardware and operating system. Hardware and software are upgrading all the time, so when your system goes wrong, for example, your system cannot support the newest CPU, you need to upgrade BIOS to keep up with the latest technology.
Page 26
Please use the default BIOS settings to restore the normal operation of the system. As NORCO constantly develops and updates BIOS settings, the following pictures are only for your reference, which may not be the same as the BIOS settings you currently use.
BIS-6620 Menlow Platform Based on Mini PC 4.1 Main Menu AMI BIOS(read-only) Displays BIOS version, date of writing, and BIOS ID. Processor(read-only) Displays some information about the central processing unit (CPU), such as the type and speed of the processor, etc.
BIS-6620 Menlow Platform Based on Mini PC 4.2 Advanced Menu Reminder: The wrong parameter settings in the following sections may cause your system malfunction, so be sure to refer to the instructions in this manual for settings!
BIS-6620 Menlow Platform Based on Mini PC 4.2.1 CPU Configuration Read-only option contains CPU detailed information, including CPU maker, model, frequent, size of level 1 cache, size of level two cache. Max CPUID Value Limit When you want to use an operating system that does not support extended CPID functions, set this project to [Enabled].
Page 30
BIS-6620 Menlow Platform Based on Mini PC Execute-Disable Bit Capability Execute Disable Bit is a hardware feature introduced by Intel in the new generation of CPUs. It can help CPUs protect themselves against malicious attacks based on buffer overflow, thus avoiding malicious attacks such as "shock wave". In addition, "Execute Disable Bit" needs the cooperation of Windows XP SP2 to work properly.
BIS-6620 Menlow Platform Based on Mini PC 4.2.2 Super IO Configuration Note: This option only has COM settings when there are DVI and HDMI interfaces on the motherboard Serial Port1 Address This item is used to set the address of serial port 1. The options are:3E8(default) ,...
Page 32
BIS-6620 Menlow Platform Based on Mini PC All serial ports can't use the same address. Serial Port2 IRQ This item is used to set the interrupt of serial port 2. The options are 3(default) ,4,5,7, 10,11. Serial Port3 Address This item is used to set the address of serial port 3. The options are:3F0(default) ,3F8,...
BIS-6620 Menlow Platform Based on Mini PC 4.2.3 Hardware Health Configuration Hardware Health Configuration This is used for hardware security detection; BIOS will display the current system temperature, CPU temperature, and other related voltage values.
BIS-6620 Menlow Platform Based on Mini PC 4.2.4 ACPI Configuration (1) General ACPI Configuration...
Page 35
BIS-6620 Menlow Platform Based on Mini PC Suspend mode Choose the power saving mode when the system is dormant. If the mode is different, the power consumption of the system is different. S3 (STR): Suspend To Ram. Repost Video on S3 Resume This is whether the display will be displayed after the control system wakes up from the S3 state.
Page 36
BIS-6620 Menlow Platform Based on Mini PC (2) Advanced ACPI Configuration ACPI Version Features Selecting the ACPI version number, different versions support different features, usually downward compatible. ACPI APIC support Choose whether to open APIC (Advanced Programmable Interrupt Controller), and the extensible system can use IRQ resources.
Page 37
BIS-6620 Menlow Platform Based on Mini PC (3) Chipset ACPI Configuration APIC ACPI SCI IRQ Enable or disable internal I/O APIC (Advanced Programmable Interrupt Controller) and multiprocessor tables. USB Device Wakeup from S3/S4 Whether to allow USB devices to wake up the system from S3 or S4.
BIS-6620 Menlow Platform Based on Mini PC 4.2.5 MPS Configuration MPS Revision Multiprocessor Specification Version Option. This option allows users to select a multiprocessor specification version based on the operating system they use. This option only works if the system contains two or more physical or logical processors. MPS has two versions of [1.1] and [1.4].
BIS-6620 Menlow Platform Based on Mini PC 4.2.6 Smbios Configuration Smbios Smi support Whether to support SMBIOS PnP Function 50-54h through SMI. [Enabled:Support], [Disabled:Not Supported].
BIS-6620 Menlow Platform Based on Mini PC 4.2.7 Remote Access Configuration Remote Access To set whether remote serial access is supported or not. The setting values are [Enabled] [Disabled].
BIS-6620 Menlow Platform Based on Mini PC 4.2.8 USB Configuration Module Version (read-only) This item displays version information of USB Module. USB Devices Enabled(read-only) This item displays USB devices connected to the motherboard. USB Function This item is used to set the number of USB interfaces open.
Page 42
BIS-6620 Menlow Platform Based on Mini PC [Enabled] to open,[Disabled] to close. SDIO Controller This item is used to set whether the SDIO interface is opened or not.,[Enabled] to open, [Disabled] to close. Legacy USB Support Setting whether to support the start-up of USB devices, that is, whether to load the relevant drivers of USB devices under DOS system, such as U disk, USB keyboard, etc.,...
BIS-6620 Menlow Platform Based on Mini PC 4.2.9 Onboard LAN Option ROM Onboard LAN Option Rom This item is used to set whether to load the on-board network card startup code. The setting values are: [Enabled] [Disabled].
BIS-6620 Menlow Platform Based on Mini PC 4.3 PCI PnP Menu Reminder: The wrong parameter settings in the following sections may cause your system to malfunction, so be sure to refer to the instructions in this manual when operating! Clear NVRAM Whether to clear NVRAM (Non-volatile Random Access Memory) data or not.
Page 45
BIS-6620 Menlow Platform Based on Mini PC Allocate IRQ to PCI VGA <Yes>: Allocation of interrupt requests to PCI VGA cards. <No>: Do not use PCI VGA card. PCI IDE BusMaster The default setting for this option is <Disabled>, i.e. the motherboard is not allowed to use the BusMaster interface, also known as the DMA/33 interface.
BIS-6620 Menlow Platform Based on Mini PC 4.4 Boot Menu Move the cursor to Boot Settings Configuration and press the < Enter > button to display the following image: Boot Setting Configuration...
Page 47
BIS-6620 Menlow Platform Based on Mini PC Quick Boot This function skips the second and third tests of memory and speeds up POST time. And every POST is a complete test. Quiet Boot This project allows you to display the supply logo on the boot screen. Setting value: [Close:Disabled],[Open:Enabled].
Page 48
BIS-6620 Menlow Platform Based on Mini PC PS/2 Mouse Support Enables or disables the use of PS/2 mouse interface. Wait For “F1” If Error If there is an error in the system self-check, wait for the user to press the F1 key. In the system start-up self-check, if the problem found is not fatal (will not cause crash or serious results), the system can still continue to work, but will display "Press'F1'to resume"...
BIS-6620 Menlow Platform Based on Mini PC 4.5 Security Menu Supervisor Password This prompt line is used to indicate whether the supervisor password has been set. If it is set, it will show "Installed"; If not, it will show "Not Installed".
BIS-6620 Menlow Platform Based on Mini PC Boot Sector Virus Protection Whether this setting opens BIOS anti-virus function. Selecting Enabled activates boot zone protection. BIOS displays a warning when a disk formatting command or a write to the hard disk boot area occurs. For example, if you write to the boot area, the following message will appear.
Page 51
BIS-6620 Menlow Platform Based on Mini PC Primary Graphics Adapter To select the preferred graphics card type. Options available:[PEG/PCI],[PCI/PEG]. Internal Graphics Mode Select Motherboard integrated graphics card display size selection, only before the installation of the driver shared memory size, installation of the driver will automatically allocate the size of...
Page 52
BIS-6620 Menlow Platform Based on Mini PC Boot Display Device Three options are available: Auto, [LCD], [CRT] and [Both (i.e., LCD and CRT)]. If set to [LCD], only LCD screen will be output when the computer starts; if set to [CRT], the system will be output to CRT display when it starts;...
BIS-6620 Menlow Platform Based on Mini PC 4.6.2 South Bridge Configuration Move the cursor to South Bridge Configuration and press < Enter >. The following screen appears: AC’97 Controller Codec AC'97 Audio selection,default:<Auto>. SLP_S4# Min. Assertion Width SLP_S4# Pin Signal effective time width,default: [1 to 2 seconds].
BIS-6620 Menlow Platform Based on Mini PC 4.7 Exit Menu Save Changes and Exit To save changes to BIOS settings and exit the settings interface, restart the computer. Press [Enter] on this item, and then press [Enter] to confirm. Discard Changes and Exit Abandon all changes and exit the settings interface.
Page 55
BIS-6620 Menlow Platform Based on Mini PC Load Failsafe Defaults Automatic loading security settings, under which the system runs at a lower performance, but achieves a higher stability settings. This setting is very useful when the user system fails.
BIS-6620 Menlow Platform Based on Mini PC Appendix Appendix 1: Driver Installation Please install the driver as per the following steps: Insert the programmed disk into CD-ROM, so installation of the driver can be made either automatically or manually. Now manually installation instructions are given as below (Take the...
BIS-6620 Menlow Platform Based on Mini PC Appendix 2:Embedding SATA Hard Drive into Windows XP Installation Disk 一、Software to be prepared 1.nLite: This software can install files for your customized Windows, integrate Service Pack and Windows security update program, and also integrate common application software (including DirectX, Net Framework, software integration package, desktop theme and driver), install Windows without any participation, and create bootable ISO CD-ROM image, etc.
BIS-6620 Menlow Platform Based on Mini PC open the file. The Driver Integration Options interface appears. Select the Text Mode Driver radio button, select “SiI 3132 controller on Windows XP/Server 2003” in the list, and click “OK”. 5. Click “Forward”, and a prompt window pops up, "Apply Changes?" and click “Yes”. After completing the changes, enter the production of the following ISO image.
Page 60
BIS-6620 Menlow Platform Based on Mini PC -o 2f 00 ; Set the timer in seconds /(in minutes o 2f 08) -o 2e f6 -o 2f IE ; Set Timer Count to 1E=30 seconds -o 2fe aa ; Lock Register C:\>...
BIS-6620 Menlow Platform Based on Mini PC Appendix 4:Glossary ACPI Advanced Configuration and Power Management. ACPI specifications allow operating system to Windows 98/98SE , Windows 2000 and control most power of the computer and its add-on. Windows ME all supports this specification, so that users can flexibly manage the power system A modern motherboard layout that replaces Baby AT.
Page 62
BIS-6620 Menlow Platform Based on Mini PC Cluster Communication Port. A universal serial communication interface, usually adopts normative DB 9 connector. DIMM Dual-Inline-Memory-Modules. It is a small circuit board with memory chipset providing 64 bit memory bus width. DRAM Dynamic Random Access Memory. It’s a general type of memory for regular computer which usually store 1 bit with a transistor and a capacitance.
Page 63
BIS-6620 Menlow Platform Based on Mini PC Universal parallel interface. A name retained by DOS to represent an interface for data transmission in parallel. Usually used to connect printers. It is a specification that allows PC to configure its external devices automatically and it works independently without the manual operation.
