AMU Oxytrace
Installation

3.11. Interfaces

3.11.1 RS232 Interface

3.11.2 Profibus (optional)

A-96.250.541 / 230320
The RS232 interface is located on the back of the AMU transmitter.
The RS232 interface is used for logger download and firmware up-
load.
To connect several instruments by means of a network or to config-
ure a PROFIBUS DP connection, consult the PROFIBUS manual.
Use appropriate network cable.
NOTICE: The switch must be ON if only one instrument is
installed, or on the last instrument in the bus
21
