Bill of Materials, PCB Layout, and Schematics

7 Bill of Materials, PCB Layout, and Schematics
This section contains the ADS8168 EVM
7.1

Bill of Materials

Table 7 lists the ADS8168 EVM BOM
Part Number Quantity
PHI-EVM-CONTROLLER 1
(Edge# 6591636 rev. B)
DC001 1
GRM155R71C104KA88D 8
C3216JB1E476M160AC 2
GRM188R71E105KA12D 7
GRM21BR71A106KE51L 6
C0603C561J5GACTU 9
GRM1885C1H122JA01D 2
06035A101FAT2A 1
150080VS75000 1
PMSSS 440 0025 PH 4
9774050360R 2
1891 4
RM3X4MM 2701 2
901-143-6RFX 1
QTH-030-01-L-D-A 1
5-146261-1 3
PBC03DAAN 1
1725698 1
TSW-112-07-G-D 1
MCT06030Z0000ZP500 9
5108 4
22
ADS8168EVM-PDK
bill of materials, PCB
Table 7. ADS8168EVM-PDK Bill of Materials
Designator Value Manufacturer
N/A Texas Instruments
N/A Any
C1, C2, C6, C8, C32, 0.1uF Murata
C33, C35, C36
C3, C4 47uF TDK
C5, C7, C9, C15, C16, 1uF Murata
C19, C21
C10, C11, C12, C13, 10uF Murata
C30, C34
C14, C17, C18, C20, 560pF Kemet
C22, C23, C24, C25,
C26
C27, C28 1200pF Murata
C31 100pF AVX
D1 Bright Green Wurth Elektronik
H1, H2, H5, H6 B&F Fastener Supply MACHINE SCREW PAN PHILLIPS 4-40
H3, H4 Wurth Elektronik
H7, H8, H9, H10 Keystone
H11, H13 APM HEXSEAL
J2 Amphenol RF
J4 Samtec
JP1, JP3, JP4 TE Connectivity
JP2 Sullins Connector
Solutions
P1 Phoenix Contact
P2 Samtec
R1, R6, R12, R15, 0 Vishay/Beyschlag
R25, R27, R28, R30,
R54
R2, R5, R10, R18 0 Keystone
Copyright © 2017, Texas Instruments Incorporated
layout, and the EVM schematics.
Description
USB Controller Board for ADC EVMs (Kit Item)
Printed Circuit Board
CAP, CERM, 0.1 uF, 16 V, +/- 10%, X7R, 0402
CAP, CERM, 47 uF, 25 V, +/- 20%, JB, 1206
CAP, CERM, 1 uF, 25 V, +/- 10%, X7R, 0603
CAP, CERM, 10 uF, 10 V, +/- 10%, X7R, 0805
CAP, CERM, 560 pF, 50 V, +/- 5%, C0G/NP0, 0603
CAP, CERM, 1200 pF, 50 V, +/- 5%, C0G/NP0, 0603
CAP, CERM, 100 pF, 50 V, +/- 1%, C0G/NP0, 0603
LED, Bright Green, SMD
ROUND STANDOFF M3 STEEL 5MM
Hex Standoff, #4-40, Aluminum, 1/4"
Machine Screw Pan PHILLIPS M3
JACK, SMA, 50 Ohm, Gold, R/A, TH
Header(Shrouded), 19.7mil, 30x2, Gold, SMT
Header, 100mil, 2x1, Gold, TH
Header, 100mil, 3x2, Gold, TH
Terminal Block, 6x1, 2.54mm, TH
Header, 100mil, 12x2, Gold, TH
RES, 0, 5%, 0.125 W, 0603
RES, 0, 1%, 0.5 W, 1206
www.ti.com
SBAU291 – November 2017
Submit Documentation Feedback
