anhanG

6.1

Technische Daten 64-2600 Serie

Max. Eingangsdruck [bar]: .............................. 40, 240
Ausgangsdruck [bar]: ..................................... 0 - 2 / 0 - 4 / 0 - 7 / 0 - 10 / 0 - 17
Design Prüfdruck: ........................................... 150% max. Eingangsdruck
Helium Leckrate innen: .................................... 1 x 10
Betriebstemperatur:
Durchflusskoeffizient: ...................................... Cv = 0,06 / Cv = 0,15
Vordruckabhängigkeit:Cv = 0,06 ..................... -0,7 %
Medienberührte Teile
Gehäuse: ...................................................... 316L Edelstahl elektropoliert oder
Membran: ..................................................... 316L Edelstahl, Hastelloy
Ventilsitz: ...................................................... PCTFE, Teflon
Feder: ........................................................... 316 Edelstahl, Elgiloy
Sonstige Teile:................................................ 316 Edelstahl, Hastelloy
6

aPPenDIx

6.1

Technical Data 64-2600 Series

Max. rated inlet pressure [bar]:........................ 40, 240
Outlet pressure ranges [bar]: ........................... 0-2 / 0-4 / 0-7 / 0-10 / 0-17
Design proof pressure: ........................................150% of max. rated pressure
Certified max. inboard leak rate: ..................... 1 x 10
Opertating temperature:
Flow capacity: ............................................... Cv = 0.06 / Cv = 0.15
Decaying inlet characteristic: Cv = 0.06 ........... -0.7 %
Media Contact Materials
Body: ........................................................... 316L SST with Electro-Polish or
Diaphragm: ................................................... 316L stainless steel, Hastelloy
Valve seat: .................................................... PCTFE, Teflon
Spring: .............................................................316 stainless steel, Elgiloy
Remaining parts: ............................................ 316 stainless steel, Hastelloy
PCTFE Sitz: ..................... -40 °C bis +60 °C
Teflon Sitz: .................... -40 °C bis +71 °C
®
Vespel Sitz: ................... -40 °C bis +177 °C
®
PCTFE seat: ............. -40 °C to +60 °C
Teflon seat: ............ -40 °C to +71 °C
®
Vespel seat: ............ -40 °C to +177 °C
®
mbar l/s He
-9
316L Edelstahl innen elektropoliert
, Vespel
®
mbar l/s He
-9
316L SST with internal Electro-Polish
, Vespel
®
