▲Fail-safe data is output by the R20 receiver only when there is no signal connection.
▲After each successful configuration, it can be verified by the flight control, ground station
or servo.
▲If the R20 is powered down or the SBUS signal cable is disconnected during verification,
the fail-safe data will not be received by the third-party device.

7.5. Channel Hold

1. Select the channel hold control switch
2. Select the gear in which the control switch triggers the hold. '0' stands for low gear, '1'
stands for medium gear and '2' stands for high gear. The three gears can be used
separately.
3. Select the channel to be held.
4. Write the data and verify the result. As shown in the figure above, if the SA is set to low
gear for SBUS-1, it can trigger the output hold of CH3, but CH03 cannot control the output
value of 03. That is, the 03 channel will always hold the current value.
The SBUS-1 and SBUS-2 channel holds operate independently of each other.
❋
The channel hold takes precedence over the throttle control.
❋
