Installation Notes
48 VDC 100Ah – (RA12-100 x 4)
24 VDC 180Ah – (RA6-180 x 4)
48 VDC 180Ah – (RA6-180 x 8)
Note: To ensure battery bank cannot be accidentally short circuited, DO NOT fit any battery
links at this stage.
Repeat 24 VDC 180Ah layout on top and bottom shelf.
IN0005 Revision 03 – 4 of 9
