The distance to the main AC Switchboard must also be considered. An AC feed into and
another AC feed out of the SP PRO are required.
C B C
HOOSING ACKUP
Significant rewiring of the installations AC switchboard may be required to split out which
circuits are required to be battery backed. The easiest (in a typical domestic application) is to
make all circuits (excluding off peak loads like hot water) battery backed as long as this doesn't
exceed the 63A feed through capacity of the SP PRO. This eliminates the need to split any
circuits out and provides a whole of house energy monitor via SP LINK however the customer
will need to manually choose which appliances to turn off during blackouts.
P SP PRO
LACEMENT OF
Wall Space Dimensions (mm) – 1250(w) x 1000(h).
The DC Switchboard has been designed to minimise cable length and cross-over of DC and AC
cabling. The DC Switchboard should be mounted at the same level and to the right of the
SP PRO. The minimum recommended width to mount both units is 1250mm. This allows for
250mm clearance either side of the SP PRO.
A P
DDITIONAL ARTS TO BE SUPPLIED
Some additional parts are required to be supplied by the installer.
AC Cabling – sized to suit maximum AC capacity.
32mm Conduit
25mm Conduit
Mounting hardware
Solar panels, cabling and isolators – if required
Note: DC Switchboard contains sufficient DIN rail space for mounting solar isolators.
Installing the Battery Enclosure
Dimensions (mm) – 765(w) x 755(h) x 525(d).
All sides and top can be removed from enclosure for access. In most cases, only one side is
required to be removed to fit and cable batteries.
IRCUITS
DC S
AND WITCHBOARD
Note: Assembly of Battery
Enclosure is covered by
separate assembly instructions
