SP PRO ABB UNO Managed AC Coupling
Installation Notes
SP PRO ABB UNO Managed AC Coupling
Introduction
The SP PRO Managed AC Coupling provides a method of linking the ABB UNO Selectronic
Certified (SCERT) inverters to the SP PRO via the AC Load supply so that regardless of whether
the grid or a generator is connected, the SP PRO can manage and control the ABB UNO string
inverters.
Each SP PRO can manage a maximum of five ABB UNO inverters by commanding each inverter
to output the right amount of power that is needed simultaneously to supply the load, export
any excess and maintain the battery bank at any particular point in time. This is done via a
communications link which also serves to retrieve all the operational data for display and
logging by the SP PRO.
Note: This document needs to be read in conjunction with the SP PRO Instruction Manual and
any relevant ABB UNO Instruction Manuals.
Applicable ABB UNO
models
Order
ABB UNO-DM-3.3/4.0/5.0/6.0-
TL-PLUS-B
ABB PVI-3.0/3.6/4.2-TL-OUTD
(See Appendix II)
ABB PVI-5000/6000-TL-OUTD
(See Appendix II)
See Appendix II for ABB PVI Managed AC Coupling installation instructions, page
No SP PRO installed? Important information
There is no special setup required if ABB UNO is not connected to an SP PRO.
This document applies for SP PRO Series 2i. SP PRO Series I is not
supported.
IN0053 Revision 04 (005312) – 1 of 43
Wireless Kit
Order code: 005316
(Optional)
✘
✘
Suitable System Application
Off Grid
POWER
PERFORMANCE
On Grid
.
24
PASSION

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP PRO 2i Series and is the answer not in the manual?

Questions and answers

Related Manuals for Selectronic SP PRO 2i Series

Summary of Contents for Selectronic SP PRO 2i Series

  • Page 1 SP PRO ABB UNO Managed AC Coupling Introduction The SP PRO Managed AC Coupling provides a method of linking the ABB UNO Selectronic Certified (SCERT) inverters to the SP PRO via the AC Load supply so that regardless of whether the grid or a generator is connected, the SP PRO can manage and control the ABB UNO string inverters.
  • Page 2  ABB UNO can only be configured while minimum 200Vdc is applied to the solar inputs.  The ABB UNO-DM-3.3/4.0/5.0/6.0-TL-PLUS-B inverters can be installed with any existing ABB Selectronic Certified inverter.  For Wireless RS485 communication, please order Wireless RS485 link kit for the following models (Order Code: 005316): ABB UNO-DM-3.3/4.0/5.0/6.0-TL-PLUS-B (see Appendix I...

  • Page 3: Installation Check List

    Refer to the pages following the tables for detailed information on each of the installation steps. Installation step Pages Install SP PROs as per manual Install and configure batteries ABB UNO must be Selectronic Certified 4 & 6 SP PRO firmware requirement – 10.01 or higher ABB UNO AC Wiring Communications Link (RS485)
  • Page 4 1. Combined maximum Fronius AC output 2. Battery bank size  SP PRO must have firmware version 10.01 or higher.  All ABB UNOs must be Selectronic Certified.  Maximum of five ABB UNOs per SP PRO.  SP PRO Series 2i...
  • Page 5 SP PRO ABB UNO Managed AC Coupling Installation Notes MINIMUM battery capacity for Solar Hybrid & Off Grid Systems Each application will have a minimum battery capacity and a maximum allowable PV, please refer to the battery manufacturer’s data sheet as well as the guidance given in the SP LINK Site Configuration Wizard.
  • Page 6 Table 3: ABB UNO compatible firmware with the SP PRO ABB UNO Must be Selectronic Certified The ABB UNO must be Selectronic Certified. Other ABB UNOs will not operate correctly with the SP PRO in a managed AC coupled configuration.
  • Page 7 SP PRO ABB UNO Managed AC Coupling Installation Notes Installation The SP PRO and ABB UNOs must be installed as per their respective installation instructions. Particular instructions directly related to Managed AC Coupling are listed below. It is good practice to number each ABB UNO from 1 up to 5 so that each inverter can be easily referenced within SP LINK.
  • Page 8 SP PRO ABB UNO Managed AC Coupling Installation Notes Communications Interface Board Link ABB UNO AC Wiring guide for Off Grid installation Note: The system will not function correctly if the ABB UNOs are installed on the AC Source side of the SP PRO. IN0053 Revision 04 (005312) –...
  • Page 9 SP PRO ABB UNO Managed AC Coupling Installation Notes Communications Link (RS485) The communication link always starts at the SP PRO and links to each of the ABB UNOs in a daisy chain arrangement. SP PRO  Expansion  Card  Sync 1  ABB UNO  Sync 2  RS485 ...
  • Page 10 SP PRO ABB UNO Managed AC Coupling Installation Notes RS485 Connection to First ABB UNO Using the supplied CAT5 network cable, connect one end to the Advanced Communications Card “RS485-2” connection on the SP PRO. At ABB UNO 01 (Address# 02), connect the CAT5 cable to the RS485 adapter cable, and terminate the adapter into the ABB communications board.
  • Page 11 SP PRO ABB UNO Managed AC Coupling Installation Notes Connecting ABB UNO link between Inverters 02 (Address# 03) to 05 (Address# 06) The following configuration outlines the connection for multiple ABB UNOs to the first ABB UNO (ABB UNO 01). If only a single ABB UNO is installed, skip to the next section page 15 (CONFIGURATION –...
  • Page 12 SP PRO ABB UNO Managed AC Coupling Installation Notes Configuration – Additional Settings The Site Configuration wizard (in SP LINK 9.9 or higher) must be used to configure the SP PRO settings. Using the wizard will ensure all SP PRO settings are compatible with the managed AC coupled system.
  • Page 13 SP PRO ABB UNO Managed AC Coupling Installation Notes ABB UNO Configuration The settings listed below are required to be configured in each ABB UNO in order for the system to operate correctly. Each ABB UNO must be set to an RS485 address from 2 to 6 as appropriate. 1.
  • Page 14 SP PRO ABB UNO Managed AC Coupling Installation Notes 7. Scroll to Set RS485 Com and press ENTER. 8. Scroll to Set Port and press ENTER. 9. Scroll to Address RS485 and press ENTER. a. If only one ABB UNO is installed then the address must be set to 2/63. b.
  • Page 15 SP PRO ABB UNO Managed AC Coupling Installation Notes a. Scroll DOWN and select Aurora (slave) and press the ENTER button to configure and return to the “Set Port” menu. 11. Press the ESC button five times to return to the main display. 12.
  • Page 16 SP PRO ABB UNO Managed AC Coupling Installation Notes System Commissioning – Additional Tests In addition to the normal system testing that would be performed, the following additional tests must be performed as detailed below. Note: Make sure that only DC is connected at this stage. Communications Link Verification The correct operation of the ABB Managed AC Coupling relies on the Communications Link.

  • Page 17: Additional Information

    3. To extend the range of the wireless devices, please order the Patch Antenna (Order code 004810). Additional information Selectronic web site – http://www.selectronic.com.au or contact the Selectronic team. Legend to diagrams in this document SD1100 RS485 Selectronic Certified SD1100 RS485...
  • Page 18 SP PRO ABB UNO Managed AC Coupling Installation Notes Overview The diagrams below illustrate the options for single phase managed AC coupled system with ABB UNO-DM inverters. Figure 1: Single phase system with one wireless ABB UNO-DM Figure 2: Single phase system with multiple wireless ABB UNO-DM IN0053 Revision 04 (005312) –...
  • Page 19 SP PRO ABB UNO Managed AC Coupling Installation Notes Installing a separate pair of wireless RS485 devices on each phase The diagram below shows a three-phase managed AC coupled system with three ABB UNOs per phase. A separate pair of Wireless RS485 link Kit (Order code 005316) must be used for each phase.
  • Page 20 (stock code 004810) Optional Patch Antenna to extend the range of the wireless devices (Selectronic Order Code 004810) Note: Patch Antenna is directional and must be mounted in a fixed position that is directly facing the antenna of the other wireless device.
  • Page 21 SP PRO ABB UNO Managed AC Coupling Installation Notes Installation Note: If you have been supplied with an “AC Coupled Interface PCA” and have an old communications card, please refer to Appendix III for instructions on how to configure RS485 communications.
  • Page 22 SP PRO ABB UNO Managed AC Coupling Installation Notes Wireless connection to ABB UNO-DM Using the supplied ‘CAT5’ network cable connect one end to the SLAVE SD1100 RS485 Wireless adaptor. At ABB UNO 01 (Address# 02), connect the CAT5 cable to the RS485 adapter cable, and terminate the adapter into the ABB communications board.
  • Page 23 SP PRO ABB UNO Managed AC Coupling Installation Notes The last ABB UNO of the daisy chain must be terminated provided jumper at the pins marked “120Ω TERM.” must be placed in the ON position as shown. Terminator Jumper Note: When connecting multiple ABB UNOs together, the terminating jumper must be set to OFF “120Ω...
  • Page 24 SP PRO ABB UNO Managed AC Coupling Installation Notes Appendix II: SP PRO ABB PVI Managed AC Coupling Introduction This section details the additional steps needed to install the managed AC Coupling system for ABB PVI-3.0/3.6/4.2-TL-OUTD and ABB PVI-5000/6000-TL-OUTD string inverters to the SP PRO.
  • Page 25 Output power of the ABB UNOs.  SP PRO must have firmware version 8.0 or greater.  All ABB UNOs must be Selectronic Certified (Selectronic signage on front access cover).  Maximum of 5 ABB UNOs per SP PRO IN0053 Revision 04 (005312) – 25 of 43...
  • Page 26 SP PRO firmware and Tech Note 34 SP PRO Firmware Update Procedure. ABB Must be Selectronic Certified The ABB UNO must be Selectronic Certified. Other ABB UNOs will not operate correctly with the SP PRO in a managed AC coupled configuration.
  • Page 27 SP PRO ABB UNO Managed AC Coupling Installation Notes Installation The SP PRO and ABB UNOs should be installed as per their respective installation instructions. Particular instructions directly related to Managed AC Coupling are listed below. It is good practice to number each ABB UNO from 1 up to 5 so that each inverter can be easily referenced within SP LINK.
  • Page 28 SP PRO ABB UNO Managed AC Coupling Installation Notes Communications Interface Board Link ABB AC Wiring guide for Off Grid installation Note: The system will NOT function correctly if the ABB UNOs are installed on the AC Source side of the SP PRO. IN0053 Revision 04 (005312) –...
  • Page 29 SP PRO ABB UNO Managed AC Coupling Installation Notes Communications Link (RS485) The communication link always starts at the SP PRO and links to the “AC Coupled Interface PCA”, then connects to all the ABB UNOs in a daisy chain arrangement and finishes at the last ABB UNO.
  • Page 30 SP PRO ABB UNO Managed AC Coupling Installation Notes ABB UNO Communication link to SP PRO Communication Card SP PRO  Expansion  Card  AC Coupled Interface  PCA supplied with  Selectronic Certified  12V DC Power  Grid Inverters    To ABB AC   To RS485  Coupled Inverter  Port 2  Sync 1  ABB UNO  Sync 2  RS485 Port 2  RS485 A  RS485 B  RS232 Port 2  RS232 Port 1  ABB UNO Comm’s  SP PRO Connections (inside unit) – RS485 Port 2 RJ45 connector to AC Coupled Interface PCA (Sergio) and to ABB UNO RS485B connector IN0053 Revision 04 (005312) –...
  • Page 31 SP PRO ABB UNO Managed AC Coupling Installation Notes ABB PVI-3.0/3.6/4.2-TL-OUTD Series RS485 Connections RS485A RS485B ABB PVI-3.0/3.6/4.2-TL-OUTD Series RS485 Connections (inside unit) – RJ45 connectors On the ABB UNO there are two RJ45 sockets allowing “looping through” of the wiring to additional inverters.
  • Page 32 SP PRO ABB UNO Managed AC Coupling Installation Notes ABB PVI-5000/6000-TL-OUTD Series RS485A RS485B ABB PVI-5000/6000-TL-OUTD Series RS485 Connections (inside unit) – RJ45 connectors On the ABB UNO there are two parallel sets of RJ45 connections allowing “looping through” of the wiring to additional inverters.
  • Page 33 SP PRO ABB UNO Managed AC Coupling Installation Notes Configuration – Additional Settings It is recommended that the Site Configuration wizard in the Easy Start Guide (in SP LINK 8.0 and above) be used to configure the SP PRO settings. Using the wizard will ensure all the SP PRO settings are compatible with the manage AC coupled system.
  • Page 34 SP PRO ABB UNO Managed AC Coupling Installation Notes ABB Port Configuration The settings listed below are all that is required. Each ABB UNO must be set to an inverter address from 2 to 6 as appropriate. Note: The ABB UNOs numbering starts from 2 to 6 instead of 1 to 5 when creating a communication link to SP Link e.g.
  • Page 35 SP PRO ABB UNO Managed AC Coupling Installation Notes To access “Settings”, a passcode is required. By default, 0000 is the passcode or by pressing the ENTER key four times to access the setting option. Use ENTER key to confirm an action or to access submenus. 14.
  • Page 36 SP PRO ABB UNO Managed AC Coupling Installation Notes 1. Scroll to the Power Reduction setting and press ENTER. Note: ABB UNOs compliant with the AS/NZS 4777.2-2015 will not contain the Power Reduction setting in the inverter. a. The ABB UNO is set to 100% as default, use the UP key to set the “Power Reduction”...
  • Page 37 SP PRO ABB UNO Managed AC Coupling Installation Notes Note: If Reactive Power is required to be configured, preform the following procedure before step 6. Reactive Power must also be set in the SP PRO that is connected to the ABB UNO. Scroll to Reactive Power setting and press ENTER.
  • Page 38 SP PRO ABB UNO Managed AC Coupling Installation Notes System Commissioning – Additional Tests In addition to the normal system testing that would be performed, the following additional tests must be performed as detailed below. Communications Link Verification The correct operation of the ABB Managed AC Coupling relies on the Communications Link.
  • Page 39 SP PRO ABB UNO Managed AC Coupling Installation Notes Appendix III: Communications Link Configuration for ABB DM PLUS with “AC Coupled Interface PCA” The communication link always starts at the SP PRO and links to the “AC Coupled Interface PCA”, then connects to all the ABB UNOs in a daisy chain arrangement and finishes at the last ABB UNO.
  • Page 40 SP PRO ABB UNO Managed AC Coupling Installation Notes ABB UNO Communication link to SP PRO Communication Card SP PRO  Expansion  Card  AC Coupled Interface  PCA supplied with  12V DC Power  Selectronic Certified  To ABB AC   To RS485  Grid Inverters    Coupled Inverter  Port 2  ABB UNO  Sync 1  Sync 2  RS485 Port 2  RS232 Port 2  RS232 Port 1  ABB UNO COM  SP PRO Connections (inside unit) – RS485 Port 2 RJ45 connector to AC Coupled Interface PCA and to ABB UNO RS485B connector IN0053 Revision 04 (005312) –...
  • Page 41 SP PRO ABB UNO Managed AC Coupling Installation Notes RS485 Connection to First ABB UNO Using the supplied ‘CAT5’ network cable connect one end to the AC Coupled Interface PCA “To ABB AC Coupled Inverter” on the SP PRO. At ABB UNO 01 (Address# 02), cut off the non- connected RJ45 connector, expose and crimp the wires using wire crimps or alternatively use a longer cable as required (not supplied) as outlined in the table below.
  • Page 42 SP PRO ABB UNO Managed AC Coupling Installation Notes Connect the three wires from the CAT5 network cable to the ABB UNO connector, +T/R, -T/R and RTN. The RS485 terminals are located on the right-hand side edge of the connector as illustrated.
  • Page 43 SP PRO ABB UNO Managed AC Coupling Installation Notes Connecting ABB UNO link between Inverters 02 (Address# 03) to 05 (Address# 06) The following configuration outlines the connection for multiple ABB UNOs to the first ABB UNO (ABB UNO 01). If only a single ABB UNO is installed, skip to the next section page 15 (CONFIGURATION –...
