Installations may be performed at different times of construction by different individuals.
For this reason, this manual should be left on-site with the facility or maintenance manager.
Read this entire installation manual to ensure proper installation, then file these
instructions with the owner or maintenance department.
Flush all the water supply lines before making connections, then make sure the water
supply is turned off before beginning installation.
Do not use pipe dope on faucet and supply connections. Possible solenoid contamination
could occur and will void any warranty. Teflon tape is the recommended sealant.
The installation site should have access to an electrical box with 120 volt AC, 60 Hz cycle
for input to a transformer. When installing the transformer, the electrical box should be
located within six feet of the sink.
The DC faucet is powered by one factory-installed 6-volt lithium battery.
Pressurized plumbing fixtures must be installed in accordance with manufacturer's
recommendations. The supply piping to these devices must be securely anchored to the
building structure to prevent the installed device from unnecessary movement when
operated by the user. Use extreme caution when installing the device to prevent damage to
the exposed significant surface.
Compliance and conformity to local codes and ordinances is the responsibility of the
installer.
Product warranties may be found under "Product Information" on our web site at
www.bradleycorp.com.
215-1558 Rev. A; EN 07-202
© 2007 Bradley Corporation
Page 1 of 8 3/8/07
Installation
Instructions
Aerada 1100 Series
High Arc Faucet
S53-304 DC High Arc Infrared Faucet
S53-305 AC High Arc Infrared Faucet
232-006 115-volt AC Plug-In Adapter
232-005 Multi-use AC Adapter (maximum
8 faucets)
232-007 4" chrome-plated Trimplate
WARNING
