Aerada 1000
Installation
Packing List
•
•
•
IS
T H
E
•
S ID
U P
215-1628 Rev. A; EN 08-201
© 2008 Bradley Corporation
Page 1 of 14
5/21/08
Aerada 1100
IMPORTANT!
Read this entire installation manual to ensure proper installation. When
fi nished with the installation, fi le this manual with the owner or maintenance
department. Compliance and conformity to local codes and ordinances is
the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for
before discarding packaging material. If any parts are missing, do not begin
installation until you obtain the missing parts.
Make sure that all water supply lines have been fl ushed and then completely
turned off before beginning installation. Do not use pipe dope. Debris in
supply lines can cause valves to malfunction.
Product warranties may be found under "Products" on our web site at
www.bradleycorp.com.
Installation
Aerada 1000 Series Faucet
S53-326 AC Gooseneck
S53-327 DC Gooseneck
Aerada 1100 Series Faucet
S53-328 AC High Arc Infrared
S53-329 DC High Arc Infrared
Table of Contents
Supplies Required . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Manual Settings . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . .9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 10
Care and Maintenance . . . . . . . . . . . . . . . . . 12
Multi-Faucet Transformer Wiring . . . . . . . . . 14
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY Fax: 262-253-4161
www.bradleycorp.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bradley AERADA 1000 Series S53-326 AC
Summary of Contents for Bradley AERADA 1000 Series S53-326 AC
- Page 1 Aerada 1000 Aerada 1100 Read this entire installation manual to ensure proper installation. When fi nished with the installation, fi le this manual with the owner or maintenance Installation department. Compliance and conformity to local codes and ordinances is the responsibility of the installer. Separate parts from packaging and make sure all parts are accounted for Packing List •...
-
Page 2: Aerada
Aerada 1000/1100 Series SAFETY INFORMATION Read this entire user guide to ensure proper installation. Compliance and conformity to local codes and ordinances is the responsibility of the installer. The following safety notes must always be complied with during handling of this product: •... -
Page 3: Component Parts
Installation COMPONENT PARTS Aerada 1100 Series 1 a/b High Arc Components & Bradley Part Nos. 1. Spout with External Mixer opening [269-1960] 2. Shut Off Screw Assembly [269-1944] 3. Outlet Assembly Kit Lavatory Spout (.5 GPM) [269-1946] 4. Mixer Kit [269-1945] 5. -
Page 4: Installation
Aerada 1000/1100 Series INSTALLATION This faucet comes with all the components needed for installation,however, some tools and supplies are not included. • Basin Wrench • Adjustable Wrench • Adjustable Locking Pliers • Plumber´s Putty • Hex Key (supplied) • Outlet Key (supplied) Do not use pipe dope on faucet and supply connections. - Page 5 Installation Start-up Operation Prerequisites • Faucet is mounted • Water supply is on • Water supply lines are fl ushed properly • For AC faucets, power outlet is installed. 1 Fully open supply valves. 2 Remove all items from sink. 3 Remove protective covering from sensor.
-
Page 6: Manual Settings
Aerada 1000/1100 Series Enabling “Manual Setting Mode” A battery model is shown in the following example. These instructions apply to all models. After 30 minutes, the “Manual Setting” mode will be disabled automatically and all settings will be saved. Prerequisites •... - Page 7 Installation 9 Mount mixer handle (only for faucets with external mixer) Result: The faucet is now mounted. A - Setting Cleaning Mode Setting the cleaning mode will make the faucet inactive for 90 seconds. 1 Enable “Manual Setting” Mode > See “Enabling Manual Setting Mode” section 2 Fully cover sensor with hand, until water fl...
- Page 8 Aerada 1000/1100 Series D - Setting Scrub Mode (60 seconds) Setting scrub mode for 60 seconds will allow the faucet to activate for 60 seconds from the last hand presence. 1 Enable “Manual Setting” Mode > see “Enabling Manual Setting Mode” section 2 Fully cover sensor with hand.
-
Page 9: Adjustments
Installation FAUCET ADJUSTMENTS Operating modes and sensor ranges can be adjusted with a manual operation through the infrared sensor. Faucet adjustment operations apply to all models. OPERATING MODES Operating Modes Description A Cleaning Mode The faucet is inactive for 90 seconds. B Normal Mode The faucet is activated if it senses a hand presence. -
Page 10: Troubleshooting
Aerada 1000/1100 Series TROUBLESHOOTING Problem Possible Cause No water fl ow Supply valves are closed Aerator is blocked or dirty Inlet water line fi lter is dirty or blocked Braided hose is kinked No external water pressure Battery is drained (DC faucets only) Battery contacts are corroded (DC faucets only) - Page 11 Installation Problem Possible Cause Water runs Connector between continuously and electronics module and stops when object solenoid valve plug is present reversed Water runs Interfering object is in continuously monitoring range Defective electronics module Improper sensor mode External water pressure too high Solenoid valve inoperable Water fl...
-
Page 12: Care And Maintenance Instructions
Aerada 1000/1100 Series CARE AND MAINTENANCE INSTRUCTIONS The following instructions are described in this section: • Activating Cleaning Mode • Replacing Battery • Cleaning or Replacing Inlet Filter • Adjusting Water Temperature (Internal Mixer) • Adjusting Hot Water Limiter (External Mixer) •... - Page 13 Installation 7 Install shut-off screw. 8 Install mixer handle (for faucets with external mixer only). Result: The battery is now replaced. Cleaning or Replacing Inlet Filter 1 Close supply valves. 2 Disconnected braided hoses and clean or replace fi lter (for a new fi...
- Page 14 Aerada 1000/1100 Series Cleaning or Replacing Aerator 1 Remove shut-off screw. 2 Remove aerator with vandal resistant wrench supplied with the faucet. Clean or replace aerator, then reinstall. Multi-Faucet Transformer Installaion Transformer can be used to connect up to 8 faucets.
