Material Support Lift

The Material Support Lift should be calibrated before machine use. Before beginning, ensure

Material Lifter is checked in the Material Support box on the Machine Library Main interface.

The Material Support Lift settings Lifter Trigger (X), Lifter Trigger (B) and Lifter Offset (B)

are determined during the machine calibration process. Once the Material Support Lift is

calibrated, the Operator should not need to adjust these settings.

In the Tube Library, in the Machine interface, the Operator can change the Lifter height by

entering the desired value in the Support Lifter Gap text box. The Support Lifter Gap is typically

set to zero. However, in the case of some larger materials, such as large square or rectangle

material, the lifter may need to be set to compensate for material size. If the Material Support

Lift is binding and/or skipping steps when processing large material, it may be necessary to

change the Support Lifter Gap. Contact a Bend-Tech Service Tech before changing these

settings.
