- Page 1 Part 1 of 1 A400 Cooling System Assembly Manual Version 3.1 | English ©2020 Bend-Tech LLC...
- Page 2 Tech LLC strives to produce the most complete and accurate information regarding its products. We are constantly working to advance our products to improve product performance, user satisfaction and experience. Bend-Tech LLC assumes no responsibility for errors or omissions regarding this manual. Bend-Tech LLC assumes no liability for damages resulting from the use of the information contained in this publication.
- Page 3 Dragon A400 Cooling System Assembly Manual Version 3.1 English Original Instructions February 2020 Bend-Tech, LLC 729 Prospect Ave. Osceola, WI 54020 USA (651) 257-8715 www.bend-tech.com support@bend-tech.com Bend-Tech Dragon A400 Cooling System Assembly Manual...
-
Page 4: Limited Warranty
This warranty does not cover components subject to wear due to normal use of the machine such as belts, lights, tooling etc. This warranty is void if Bend-Tech, LLC has determined any failure is the result of mishandling, abuse, misuse, improper installation, improper storage, improper maintenance or unauthorized modification of the machine. -
Page 5: Customer Service
Dragon A400. Bend-Tech, LLC places great pride in customer satisfaction and it is our promise to offer you the best support available for your Dragon A400. We recognize that our support is a key factor in your success. -
Page 6: Warnings
Example ! Danger ! Exceeding the material weight limit of the Dragon A400 can result in serious injury to the operator and/or bystanders. Warning A Warning indicates there is a possibility for minor injury if the instructions are not followed correctly. - Page 7 A Note gives clarification or focuses on information that is critical or unique to an operation. Example Water Cooling system greatly reduces smoke and vapor emitted by the machine. Bend-Tech recommends use of the Water Cooling system whenever possible. Bend-Tech Dragon A400 Cooling System Assembly Manual...
-
Page 8: Glossary
System for connecting multiple computers via a Local Area Network. Axis Front Gate A fixed reference line used by the Dragon A400. The Gate supports the material at the front of the machine. It consists of two Bend-Tech 7X sets of self-centering roller jaws. -
Page 9: Table Of Contents
2.2.7 C Bracket ....18 2.17 Male Plug Coupler ... . . 25 Bend-Tech Dragon A400 Cooling System Assembly Manual... -
Page 10: Contents
Contents Cooling System Assembly Manual Bend-Tech Dragon A400... -
Page 11: Parts And Equipment
• Disposable Mesh Bags (2) • Flanged hex head screws (8) • 8 in. zip ties (8) • ⅜ nyloc nuts (4) • ¾ in. FGHT x ½ in. FIP + Male Coupler Bend-Tech Dragon A400 Cooling System Assembly Manual... -
Page 12: Tools And Equipment
• ⅜ in. Ratchet • 7/16 in. socket • 9/16 in. socket • Cordless drill or driver with ⅜ in. drive or adapter • 9/16 in. wrench • ½ in. wrench • Flat head screwdriver Cooling System Assembly Manual Bend-Tech Dragon A400... -
Page 13: Cooling System Assembly
The Cooling System also reduces plasma dust and toxic gas during the cutting process. While the Cooling System will help the Dragon A400 achieve cleaner cuts on any material, it is especially effective when cutting aluminum and stainless steel. -
Page 14: Water Tray System Components
2.2.1 Parts Catcher and Support Leg Removal If the Installer is adding a Cooling System to a Dragon A400 machine that has already been assembled and run without a Cooling System, it will be necessary to remove the Parts Catcher, Parts Tray and Support Leg from the Beak of the machine. -
Page 15: Leveling Feet
Do 4 Bolts not tighten the nuts at this time. per side 2.2.5 Attach Water Tray to Parts Bend-Tech recommends enlisting a helper when assembling the Water Tray System. Bend-Tech Dragon A400 Cooling System Assembly Manual... -
Page 16: Catcher
Water Tray and the nut and washer are on the outside. Beak Parts Catcher Support Leg Use a punch or small Phillips head screwdriver to help align the mounting holes in the Water Tray system. Cooling System Assembly Manual Bend-Tech Dragon A400... -
Page 17: Water Tray System Assembly
1 in. button head screws, nuts and Support Leg Brace washers. Ensure the heads of the screws are on the inside of the water tray and the nuts and washers are on the outside. Do not tighten. Support Leg Bend-Tech Dragon A400 Cooling System Assembly Manual... -
Page 18: C Bracket
Attach the bent end of the Aluminum Support Leg Brace to the outside of the Water Tray, feeding the button head screw from the inside of the Water Tray and the nut and washer are on the outside. Cooling System Assembly Manual Bend-Tech Dragon A400... -
Page 19: Braces
Also thread one PVC coupler into the bung inside the parts catcher. This will allow the Parts Catcher to hold water to help cool parts. Teflon tape or plumber’s tape can help seal the male/female coupler in the drain bung. Bend-Tech Dragon A400 Cooling System Assembly Manual... -
Page 20: Pvc Drain Installation
The Cooling System requires the addition of a water pump to be operational. Because customer needs can vary, Bend-Tech does not supply a water pump with the Cooling System. The Customer will be required to supply a water pump to complete the Cooling System. Refer to section 2.4.1 for water pump specifications. -
Page 21: Water Pump Requirements
Attach the wireless remote-control outlet to the water pump power cord, and then the yellow GFCI power cable to the remote-control outlet. Bend-Tech Dragon A400 Cooling System Assembly Manual... -
Page 22: Attaching The Hose To The Rail Beam
⅜ in. x 1 in. hex bolts. Tighten the bolts securely using a 9/16 in. socket and ratchet. 3/8 in. x 1 in. Bolts 2.10 Hose Reel The Hose Reel is heavy, enlist help during the mounting process. Cooling System Assembly Manual Bend-Tech Dragon A400... -
Page 23: Trolley Hose Mount
Remove the two screws at the front of the Trolley cover, just above the Chuck. Place the Trolley Hose Mount hose mount on the Trolley cover. Fasten to the Trolley cover using the two Trolley cover screws. Bend-Tech Dragon A400 Cooling System Assembly Manual... -
Page 24: Connect The Hose
Using the silicone sealant, place a bead of silicone around all gaps and seams in the Water Tray System. Use a finger to spread the silicone evenly along the gaps and seams. Allow to cure before using the Coolant System. Cooling System Assembly Manual Bend-Tech Dragon A400... -
Page 25: Control Box Cover
Fit the Control Box Cover in the space above the Control Box. The Control Box Cover fits tightly in the space above the Control Box with no fasteners. Bend-Tech recommends applying silicone around the edges of the Control Box Cover to help seal out water that may spill onto it. - Page 26 Cooling System Assembly Cooling System Assembly Manual Bend-Tech Dragon A400...
- Page 28 Bend-Tech, LLC 729 Prospect Ave. Osceola, WI 54020 1-651-257-8715 sales@bend-tech.com www.bend-tech.com...
