Austausch Fahrertaster
Beschaltung X1/4:
24V
Verdeck öffnen
0V
Verdeck schließen
unbeschaltet
Verdeck steht still
!
Nicht zusammen mit Funkbedienung
installierbar
www.EdschaTS.com
X1/4
Fahrertaster
Kippverdeck
X1/4
Driver switch
tipper roof
EN
Replacing the driver switch
Wiring X1/4:
24V
open roof
0V
close roof
unbeschaltet
roof stops
!
Cannot be installed together with the remote
control
Batterie +
Battery +
Batterie -
Battery -
