TipperRoof Troubleshooting 1/2
Malfunction / Problem
When moving, the roof gets stuck at
one point
The swing arm goes up with difficulty
The swing arm only goes up on the
operation side and the roof moves with
difficulty
The swing arm easily goes up, but not
down
The swing arm won't go up
The swing arm beats when driving over
approx. 70 km/h
The first roller carriage doesn't go (fully)
to the front and/or the last segment is
not the last to fold up
The middle roller carriage doesn't go
(fully) to the front and/or the last seg-
ment is not the last to fold up
www.EdschaTS.com
Possible cause
An object is clamped on the rail
The rail is damaged
Rail fitting is loose
Rail joint is misaligned
Guide roller damaged at left end stop
The guide roller is worn out
Connection screws of the end bow are
loose/damaged
The rotary axe of the swing arm is missing
Control lever passes by the guide roller
Guide roller missing at right end stop
Control lever passes by the guide roller
Control lever is missing
Rear spoiler defective
Rear roof not locked
An object is clamped on the rail
The rail is damaged
The guide roller is damaged
The guide roller is worn out
Bracket is adjusted too wide or too narrow
An object is clamped on the rail
The rail is damaged
The guide roller is damaged
The guide roller is worn out
Bracket is adjusted too wide or too narrow
Recommended remedy
Remove it and clean the rail
Repair or replace the segment
Refit it and tighten
Align the rail / smooth the transition
Replace it
Replace it
Tighten / replace
Replace it
Adjust the lever
Replace it
Adjust the lever
Replace it
Replace rear spoiler
Open the roof and close it again until it
snaps into place
Remove it and clean the rail
Repair or replace the segment
Replace it
Replace it
Do not drill it out, rivet it again,
without tension
Remove it and clean the rail
Repair or replace the segment
Replace it
Replace it
Do not drill it out, rivet it again, without
tension
