Invacare Matrx ELITE E2S User Manual page 12

3.5.2 B H
ACK
WARNING! Risk of Damage or Injury
Improper mounting pin set-up may cause damage to the back pan and/or the
mounting plates. Ensure sufficient space is provided between the mounting plate
and the heads of the mounting pins (a minimum gap of 1/8" -1/4" (3mm-
6mm) is recommended).
The vertical (height) adjustment slots on each E2S/E2D back shell will vary in
length depending on the nominal back height- refer to Table 1.
Table 1. BACK SHELL: RANGE OF HEIGHT ADJUSTMENT
Back Height Adjustment Range
6" (15cm) 1.25" (32mm)
8" (23cm) 1.5" (38mm)
10" (26cm) 2.0" (51mm)
NOTE: During final set-up, we recommend having the end user seated
in the wheelchair to best fit/position the Elite E2S/E2D back.
Back Height and Width Adjustment: (see Fig. 7, Fig. 8)
1. With the E2S/E2D back locked into place, and the end user seated in the chair
(if possible), carefully adjust the back shell along the vertical adjustment slot
(A)(1) until the desired back height is achieved.
NOTE: the minimum recommended back height* is
the top of the seat
2. While maintaining the desired back height, adjust each mounting bracket (B)
horizontally (2) so that a minimum gap of 1/8-1/4" (3-
the heads of the mounting pins (C) and the mounting plate (D).
NOTE: Unless otherwise necessary, the Elite E2S/E2D back should be centered
between the back canes during installation.
3. Once all height and width adjustments are finalized, fully tighten/secure both
mounting brackets into position.
4. Proceed to section 3.5.3 for Back Angle and Depth Adjustment
*Note: The minimum recommended back height is provided as a guideline only.
The final back height should be adjusted/set to best meet the end user's needs-
see Important! note below.
IMPORTANT! Always ensure that the bottom of the back is positioned
anatomically below the Posterior Superior Iliac Spine (PSIS). If you have any
questions or concerns regarding proper back height adjustment, please contact
your Motion Concepts representative for assistance.
W
EIGHT AND IDTH
surface.
A :
DJUSTMENT
Back Height
12" (31cm)
14", 16" (36, 41cm)
18", 20" (46, 51cm)
- 12 -
Adjustment Range
2.5" (63mm)
3.5" (89mm)
3.25" (83mm)
4"- 5" (10-13
cm
) exists between
6mm
) from
