Summary of Contents for Invacare Matrx E2 BACK
- Page 1 Invacare Matrx ® ® E2 B (E2S/E2D) USER MANUAL DEALER: This manual MUST be given to the user of the product. USER: Before using this product, read this manual and save for future reference. TRD0665 Rev A...
- Page 2 en This manual may not be reproduced or reprinted either partly or completely without previous written consent from Motion Concepts or its statutory representatives. This user manual is compiled from the latest specifications and product information available at the time of publication. We reserve the right to make any necessary as they become necessary.
-
Page 3: User Warning
1.1 OVERVIEW SAFETY SYMBOLS: ® ® Proper set-up and safe use of your Invacare Matrx E2S/E2D Back depends on your own good judgement and common sense, as well as that of your provider, caregiver and/or health professional. The following symbols are used throughout this user manual to identify warnings, cautions and important notes. - Page 4 2.1 TRANSPORTATION WARNINGS! WARNING! Risk of Death, Serious Injury or Damage • Risk of severe injury when transporting the client within a wheelchair fitted with ® ® an Invacare Matrx E2 Back in a motor vehicle. RANSPORTING THE LIENT IN A...
-
Page 5: General Safety And Installation Warnings
•DO NOT smoke while using this wheelchair WARNING! Risk of Serious Injury ® ® When establishing the mounting position for the Invacare Matrx Back, ensure the stability of the wheelchair is not compromised. Adjusting the forward and aft position and/or angle of the backrest will alter the user’s center of gravity within the wheelchair. -
Page 6: Care And Maintenance
Matrx E2 back shell being installed. E2 Back heights of 16” (41cm) or greater require our EasySet Hardware (PBMH). E2 Back heights less than 16” (41cm) utilize our MiniSet Hardware (MSMH). - Page 7 ENERAL LEANING Outer Cover • The knitted fabric side of the E2 cover can be wiped with a damp absorbent towel, cloth, or paper towel. Remove all gross contamination from surface (i.e. food particles, urine, feces, blood). Spot-clean with mild soap and water. Back Shell/Hardware: •...
-
Page 8: Warranty Information
This warranty is extended only to the original purchaser/user of our products. This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare/ Motion Concepts warrants this product to be free from defects in materials and workmanship for two years of use by original purchaser. - Page 9 CONCEPTS; PRODUCTS DAMAGED BY CIRCUMSTANCES BEYOND INVACARE’S/MOTION CONCEPTS’ CONTROL; PRODUCTS REPAIRED BY ANYONE OTHER THAN AN INVACARE/ MOTION CONCEPTS DEALER, SUCH EVALUATION SHALL BE SOLELY DETERMINED BY INVACARE/ MOTION CONCEPTS. THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES, IF ANY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
- Page 10 6.0 E2 B CCESSORIES 6.1 E2 HEADREST INTERFACE PLATE The E2 Headrest Interface Plate (A) is included only with E2 Backs for Back Heights ranging from 14” (36cm) up to 20” (51cm). The E2 headrest interface is compat- ible with most industry standard headrest mounting hardware, including our Matrx Elan Headrest Hardware (sold separately).
- Page 11 6.3 ADDITIONAL E2 ACCESSORY OPTIONS (Sold Separately) PRIVACY FLAP (PFLAP) II. BACKBONE (PSIS/SacroLumbar Support) III. POSTURE FLEX (Abdominal Support) QUAD RELEASE (QR) TAB IV. CHEST HARNESS INTERFACE V. EASYFIX LATERALS VI. SWING-AWAY LATERALS III. - 11 -...
- Page 12 Motion Concepts. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.
