ST9 EPB
User Manual
Release 1.1
May 2001
Ref: DOC-ST9WIN-EPBJ/LPT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST9 EPB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ST ST9 EPB

Summary of Contents for ST ST9 EPB

  • Page 1 ST9 EPB User Manual Release 1.1 May 2001 Ref: DOC-ST9WIN-EPBJ/LPT...
  • Page 2 INSTRUCTIONS FOR USE—WARNING This product is an FCC Class-A apparatus. In a residential environment, it may cause radioelectrical disturbances. In addition, this programming board is not contained in an outer casing; consequently, it cannot be immune against electrostatic discharges (ESD). It should therefore be handled only in static safe working areas.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction ......... . 5 Overview .......................
  • Page 4 Table of Contents 4/24...

  • Page 5: Chapter 1: Introduction

    Appendix B: Current ST9 EPBs on page 19. Note: The ST9 EPB is meant to program small numbers of microcontrollers (i.e. prototypes in the development stage). For mass production programming, it is recommended that you use the appropriate gang programmer.

  • Page 6: Hardware Features

    OSD, EEPROM and FLASH versions of the ST9 family. In Situ Programming (ISP) is also available for the FLASH devices. Software features A host PC running the STVP9 is the control interface for the ST9 EPB. STVP9 is a graphical Windows interface that lets you: ®...

  • Page 7: Chapter 2: Getting Started

    To set up the ST9 EPB hardware, follow these instructions: 1 Shut down and power-off the host PC. 2 Connect one end of the supplied parallel cable to connector P1 of the ST9 EPB and the other end to one of the host PC’s parallel ports (LPT1 or LPT2).

  • Page 8: Installing The Stvp9 Software

    2 - Getting Started ST9 EPB User Manual Installing the STVP9 software Your ST9 EPB comes with the MCU on CD CD-ROM which contains STVP9 and a ® number of other ST9 software tools. These tools are compatible with Windows ®...

  • Page 9: Chapter 3: How To Program

    HOW TO PROGRAM Programming methods Your ST9 EPB programming board is provided with at least one Zero Insertion Force (ZIF) socket which allows the programming of packaged MCUs. In addition to classic MCU programming using ZIF sockets, those MCUs with FLASH memories can be programmed using the In Situ Programming (ISP) mode.

  • Page 10: A Typical Programming Session

    A typical programming session The following instructions describe how you would typically program an ST microcontroller using STVP9. Note that this is not the only way to program an ST microcontroller using STVP9; for more information on how to use the STVP9, click the Help command in the main menu bar.
  • Page 11 Note: The list of supported devices shown in the screen capture above is not necessarily complete—this list grows with each new version release of STVP9. 4 Click on the Select Device tab of the ST Visual Programmer Configuration window. 11/24...
  • Page 12 Programming (ISP) 5 From the list shown in the Select Device tab of the ST Visual Programmer Configuration window, select the device to be programmed. 6 Click Apply to save your changes without closing the dialog box, or OK to save your changes and close the dialog box.
  • Page 13 To open a file you’ve used recently, click its name at the bottom of the File menu. 13 FOR EPROM and FLASH ONLY: From the main menu, select Verify>Blank Check to check that the ST microcontroller memory has not already been programmed. (You cannot perform a blank check on EEPROM memory).
  • Page 14 3 - How to Program ST9 EPB User Manual 14/24...

  • Page 15: Chapter 4: In Situ Programming Mode

    ST9 EPB User Manual 4 - In Situ Programming mode IN SITU PROGRAMMING MODE Microcontrollers with FLASH memories can be programmed using the In Situ Programming (ISP) mode (also referred to as in-system programming). ISP mode allows the contents of the ST9 program memory to be updated using a standard ST9 programming tool after the device is mounted on the application board.

  • Page 16: Setting Up The Epb For Isp Mode

    10, taking care to choose a device with an -ISP suffix from the Select Device tab of the ST Visual Programmer Configuration window. STVP9 will check the contents of the driver device installed on the EPB and update it if necessary.

  • Page 17: Appendix A: User And Work Environment Precautions

    ST9 EPB User Manual Appendix A: User and Work Environment Precautions APPENDIX A: USER AND WORK ENVIRONMENT PRECAUTIONS The following precautions are recommended when using the programming board: • Any tester, equipment, or tool used at any production step or for any manipulation of semi-conductor devices should have its shield connected to ground.
  • Page 18 Appendix A: User and Work Environment Precautions ST9 EPB User Manual 18/24...

  • Page 19: Appendix B:current St9 Epbs

    ST9 EPB User Manual Appendix B: Current ST9 EPBs APPENDIX B:CURRENT ST9 EPBS Supported Memory Types / Salestype Package Devices Programming Options PQFP80 ST90158 ST90158LV ST90E158-EPB2 TQFP80 ST90158 ST90158LV OTP, EPROM QFP80 ST90158 ST90158LV LCC84 ST90158 ST90158LV SDIP56 ST92175 ST92E175-EPBJ...
  • Page 20 Appendix B: Current ST9 EPBs ST9 EPB User Manual Supported Memory Types / Salestype Package Devices Programming Options TQFP100 ST92F150x1 ST92F150x9 ST92F124x1 ST92F124x9 PQFP100 ST92F150x1 ST92F150x9 FLASH, EEPROM ST92F150-EPB ST92F124x1 ISP mode supported ST92F124x9 TQFP64 ST92F150x1 ST92F150x9 ST92F124x1 ST92F124x9 20/24...

  • Page 21: Product Support

    PRODUCT SUPPORT If you experience any problems with this product or if you need spare parts or repair, contact the distributor or ST sales office where you purchased the product. Getting prepared before you call Collect the following information about the product before contacting ST or your distributor: 1 Name of the company where you purchased the programmer kit.

  • Page 22: Software Updates

    Sydney (61-2) 9580 3811 Taipei (886-2) 2378-8088 Software updates You can get software updates from the ST Internet web site http://mcu.st.com. For information on firmware and hardware revisions, call your distributor or ST using the contact list given above. 22/24...

  • Page 23: Index

    Index Index driver MCU ............15 parallel connection restrictions/requirements ......7 parts delivered with EPB ........7 power supply restrictions/requirements ......7 programming current list of ..........19 a typical session with STVP9 ....10 obtaining board layouts....... 9 instructions ..........9 setting up ............
  • Page 24 This publication supersedes and replaces all information previously supplied. STMicroelectronics products are not authorized for use as critical components in life support devices or systems without the express written approval of STMicroelectronics. The ST logo is a registered trademark of STMicroelectronics. ® Intel is a U.S.
