Flowserve PolyChem GRP Series User Instructions page 7

1.6.4.2 Marking
An example of ATEX equipment marking is shown
below. The actual classification of the pump will be
engraved on the nameplate.
II 2 GD c IIC 135 ºC (T4)
Equipment Group
I = Mining
II = Non-mining
Category
2 or M2 = high level protection
3 = normal level of protection
Gas and/or dust
G = Gas
D = Dust
c = Constructional safety
(in accordance with EN13463-5)
Gas Group (Equipment Category 2 only)
IIA – Propane (typical)
IIB – Ethylene (typical)
IIC – Hydrogen (typical)
Maximum surface temperature (Temperature Class)
(see section 1.6.4.3.)
1.6.4.3 Avoiding excessive surface temperatures
ENSURE THE EQUIPMENT TEMPERATURE
CLASS IS SUITABLE FOR THE HAZARD ZONE
Pumps have a temperature class as stated in the
ATEX Ex rating on the nameplate. These are based
on a maximum ambient of 40 ºC (104 ºF); refer to
Flowserve for higher ambient temperatures.
The surface temperature on the pump is influenced
by the temperature of the liquid handled. The
maximum permissible liquid temperature depends on
the ATEX temperature class and must not exceed the
values in the table that follows:
Temperature class Maximum surface
to EN13463-1 temperature permitted
T6 85 °C (185 °F)
T5 100 °C (212 °F)
T4 135 °C (275 °F)
* The table only takes the ATEX temperature class into
consideration. Pump design or material, as well as component
design or material, may further limit the maximum working
temperature of the liquid.
The temperature rise at the seals and bearings and
due to the minimum permitted flow rate is taken into
account in the temperatures stated.
Page 7 of 52
USER INSTRUCTIONS POLYCHEM GRP ENGLISH 71569132 12-04A
The responsibility for compliance with the specified
maximum liquid temperature is with the plant
operator.
Temperature classification "Tx" is used when the liquid
temperature varies and when the pump is required to be
used in differently classified potentially explosive
atmospheres. In this case the user is responsible for
ensuring that the pump surface temperature does not
exceed that permitted in its actual installed location.
Do not attempt to check the direction of rotation with the
coupling element/pins fitted due to the risk of severe
contact between rotating and stationary components.
Where there is any risk of the pump being run against a
closed valve generating high liquid and casing external
surface temperatures fit an external surface
temperature protection device.
Avoid mechanical, hydraulic or electrical overload by
using motor overload trips, temperature monitor or a
power monitor and make routine vibration monitoring
checks.
In dirty or dusty environments make regular checks
and remove dirt from areas around close clearances,
bearing housings and motors.
1.6.4.4 Preventing the build up of explosive
mixtures
AND VENTED AND DOES NOT RUN DRY
Ensure the pump and relevant suction and discharge
pipeline system is totally filled with liquid at all times
during the pump operation so that an explosive
atmosphere is prevented. In addition it is essential to
make sure that seal chambers, auxiliary shaft seal
systems and any heating and cooling systems are
properly filled.
Temperature limit of
If the operation of the system cannot avoid this
liquid handled
condition, fit an appropriate dry run protection device
Consult Flowserve
(for example liquid detection or a power monitor).
Consult Flowserve
115 °C (239 °F) *
To avoid potential hazards from fugitive emissions of
vapour or gas to atmosphere the surrounding area
must be well ventilated.
1.6.4.5 Preventing sparks
contact, the coupling guard must be non-sparking for
Category 2.
ENSURE THE PUMP IS PROPERLY FILLED
To prevent a potential hazard from mechanical
