PHA-06:
This kit contains a replacement red wired Alligator Clip (with Fuse) and a black Alligator Clip.
PHP Kit-05MM-01:
pler. Be sure to order the PHP KIT-02 to replace the Bottom Gasket and O-ring.
PH6 KIT-02: This kit contains a replacement Polypropylene Pump Housing and (6) screws.
This kit is an assembly of the Bottom Housing and the male 3-pin Micro-Matic Cou-
PH6 Service Kits:
Several service kits are available that
allow reworking the PH6 pumps. Stand-
ard materials and configurations are un-
derlined.
PHP KIT-01:
This cartridge kit is the
cartridge kit that includes the Pump Car-
tridge with Santoprene / EPDM dia-
O-ring and Bottom Gasket.
phragm,
PHP KIT-01V:
Same as the PHP
KIT-01, but with a Viton O-ring and Bot-
tom Gasket.
PHP KIT-02:
This gasket kit contains
a replacement EPDM Bottom Gasket
and O-ring (no Pump Cartridge).
PHP KIT-02V:
Same as the PHP
KIT-02, but all materials are Viton.
PHP KIT-03:
This power switch kit
contains a replacement On/Off Toggle
Switch, Molded Junction Box Cover, and
screws.
PH6 KIT-01:
This kit contains a re-
placement Nylon Pump Housing and (6)
screws.
PH6M01:
This motor kit contains a
replacement Motor Assembly consisting
of the 12-volt motor assembly with Ca-
bles, Terminal Connection Clamps, and
Wobble Plate.
Advertisement
Table of Contents
Related Manuals for Flowserve PH6
Summary of Contents for Flowserve PH6
- Page 1 This kit is an assembly of the Bottom Housing and the male 3-pin Micro-Matic Cou- pler. Be sure to order the PHP KIT-02 to replace the Bottom Gasket and O-ring. PH6 KIT-02: This kit contains a replacement Polypropylene Pump Housing and (6) screws.
- Page 3 Depending on pump model and mounting arrangement the pump can be mounted in either a vertical or horizontal (optional accessories required) position. -Vertical Mounting (PH6 Pump, PH6P, and varieties): 1. Secure pump to tank using appropriate customer supplied fitting. 2. Secure 1-inch hose to the 1-inch discharge port of pump.
- Page 4 - DO NOT run pumps continuously for longer then 30 minutes under a no flow (dead headed) situation. - DO NOT over tighten plastic threaded connections. Breakage can occur, resulting in fluid exposure. - If valve on end of hose is equipped with an internal check valve that does not allow air removal the pump may need to be primed first in order to build up enough pressure to expel air in the system.
