- Page 1 CM2-ATT082-2002 ATT082 Temperature transmitter Brief User's Manual...
- Page 2 In no event shall Azbil Corporation be liable to anyone for any indirect, special or consequential damages. This information and specifications in this document are subject to change without notice.
-
Page 3: Table Of Contents
Table of Contents Chapter 1. Important document information ........1 1-1. - Page 4 Chapter 6. Operating options ........... . 17 6-1.
-
Page 5: Chapter 1. Important Document Information
Handling Precautions: Handling Precautions indicate items that the user should pay attention to when handling the ATT082. To use this product correctly and safely, always observe the following precautions. We are not responsible for damage or injury caused by the use of the product in violation... -
Page 6: Handling Precautions For This Product
Chapter 1 Important document information 1-2-1. Handling Precautions for This Product Installation Precautions WARNING When installing, use proper fittings and proper tightening torque for connections to the process and to the exhaust. Gas leakage is dangerous because process gas and calibration gas are flammable. - Page 7 Chapter 1 Important document information Maintenance Precautions WARNING When removing this device for maintenance, be careful of residual pressure or residual process gas. Leakage of process gas is dangerous. When working on the vent, check its direction so that people do not come into contact with vented gas.
- Page 8 Chapter 1 Important document information...
-
Page 9: Chapter 2. Basic Safety Instructions
Chapter 2 Basic safety instructions Chapter 2. Basic safety instructions 2-1. Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill thefollowing requirements: • Trained, qualified specialists must have a relevant qualification for this specific functionand task •... - Page 10 Chapter 2 Basic safety instructions...
-
Page 11: Chapter 3. Identification
XXXXXXXXXXXXX# EH 08.001X II3G Ex nA II T6/T5/T4 Ta= -40 ...+ 55/70/85°C II3G Ex nL IIC T6/T5/T4 Ta= -40 ... +55/70/85°C ATT082-XXXXX Install per CM2-ATT082-2001 12345678ABCDEFGH Made in Germany 2011 12345678ABCDEFGH D-87484 Nesselwang Figure 3-1. Nameplate of the head transmitter (example, Ex version) 1. -
Page 12: Ce Mark, Declaration Of Conformity
Chapter 3 Identification 3-4. CE mark, Declaration of Conformity The device therefore meets the legal requirements of the EC guidelines. The manufacturer confirms that the device is compliant with the relevant guidelines by applying the CE mark. ® 3-5. HART Protocol Certification ®... -
Page 13: Chapter 4. Installation Instructions
Chapter 4 Installation instructions Chapter 4. Installation instructions 4-1. Incoming acceptance, transport, storage 4-1-1. Incoming acceptance • Is the packaging or content damaged? • Is the delivery complete? Compare the scope of delivery against the information on your order form. 4-1-2. -
Page 14: Installation Instructions
Chapter 4 Installation instructions 4-3. Installation instructions A Phillips head screwdriver is required to mount the head transmitter. Handling Precautions: Do not overtighten the mounting screws as this could damage the head transmitter. >> Maximum torque = 1 N·m (3/4 pound-feet). 4-3-1. -
Page 15: Chapter 5. Wiring
Chapter 5 Wiring Chapter 5. Wiring CAUTION Switch off power supply before installing or connecting the device. Failure to observe this may result in destruction of parts of the electronics. Supply electric power correctly according to the specifications. Supplying power that differs from the specifications can damage the device. -
Page 16: Connecting The Sensor Cables
3- wire 4- wire 2-wire — ✓ ✓ ✓ RTD or resistance 3-wire — ✓ ✓ ✓ Sensor transmitter 4-wire — — — — input 2 Thermocouple (TC), ✓ ✓ ✓ ✓ voltage transmitter * Refer to CM2-ATT082-2003, Functional Safety Manual. -
Page 17: Connecting The Power Supply And Signal Cables
Chapter 5 Wiring 5-3. Connecting the power supply and signal cables CAUTION Switch off power supply before installing or connecting the transmitter. Failure to observe this may result in destruction of parts of the electronics. Cable specification • A normal device cable suffices if only the analog signal is used. •... -
Page 18: Shielding And Grounding
Chapter 5 Wiring 5-4. Shielding and grounding Optimum electromagnetic compatibility (EMC) can only be guaranteed if the system components and, in particular, the lines are shielded and the shield forms as complete a cover as possible. ® HART communication allows three different types of shielding: •... -
Page 19: Post-Connection Check
Chapter 5 Wiring 5-5. Post-connection check Device condition and specifications Notes Is the device or cable undamaged (visual check)? Electrical connection Notes • Head transmitter: U=11 to 42 V DC Does the supply voltage match the • SIL mode: U=11 to 32 V DC for the head specifications on the nameplate? transmitter or U=12 to 32 V DC for the DIN rail transmitter... - Page 20 Chapter 5 Wiring...
-
Page 21: Chapter 6. Operating Options
Chapter 6 Operating options Chapter 6. Operating options 6-1. Measured value display and operating elements 6-1-1. Option: Display with transmitter Figure 6-1. Attach the display to the transmitter 6-1-2. Display elements Head transmitter Figure 6-2. Optional LC display for head transmitter Item No. -
Page 22: Local Operation
Chapter 6 Operating options 6-1-3. Local operation Handling Precautions: ESD - electrostatic discharge. Protect the terminals from electrostatic discharge. Failure to observe this may result in destruction or malfunction of parts of the electronics. 1: Connection to head transmitter 2: DIP switch (1 to 64, SW/HW, ADDR and SIM = simulation mode) no function for this head transmitter ADDR ACTIVE... -
Page 23: Chapter 7. Commissioning
Chapter 7 Commissioning Chapter 7. Commissioning 7-1. Post-installation check Before commissioning the measuring point make sure that all final checks have been carried out: • Checklist “Post-installation check” (Refer to page 10) • Checklist “Post-connection check” (Refer to page 15) 7-2. - Page 24 Chapter 7 Commissioning...
-
Page 25: Appendix A. Explosion Protected Models
Appendix A Explosion protected models Appendix A. Explosion protected models A-1. FM intrinsically safe, nonincendive and suitable approvals 図番 DWG.NO 80396231... - Page 26 Appendix A Explosion protected models 図番 DWG.NO 80396232...
- Page 28 1. Warranty period and warranty scope 1.1 Warranty period Azbil Corporation's products shall be warranted for one (1) year from the date of your purchase of the said products or the delivery of the said products to a place designated by you.
- Page 29 Although acceleration of the above situation varies depending on the conditions or environment of use of the products, you are required not to use any Azbil Corporation's products for a period exceeding ten (10) years unless otherwise stated in specifications or instruction manuals.
- Page 31 Document Number: CM2-ATT082-2002 Document Name: ATT082 Temperature transmitter Brief User's Manual Date: 1st edition: May 2015 2nd edition: July 2016 Issued/Edited by: Azbil Corporation...
