OM2-5220-0000
Liquid Level Meter
Pneumatic Transmitter
Model KDP/KKP
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KDP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Azbil KDP Series

  • Page 1 OM2-5220-0000 Liquid Level Meter Pneumatic Transmitter Model KDP/KKP User's Manual...
  • Page 2 In no event shall Azbil Corporation be liable to anyone for any indirect, special or consequential damages. This information and specifications in this document are subject to change without notice.
  • Page 3: Table Of Contents

    Table of Contents Chapter 1. Description ............1 1-1.
  • Page 5: Chapter 1. Description

    Chapter 1. Description 1-1. General The Pneumatic Transmitter (Model K_P), in conjunction with respective type of detector (meter body), is used to detect and transmit a process pressure, differential pressure, liquid level, or specific-gravity. This manual covers the structure and maintenance of the transmitter itself and adjustment of the transmitter coupled with the meter body.
  • Page 6: Combinations With Detector (Meter Body)

    1-3. Combinations with detector (Meter body) Measured Range or Type Model No. Operator’s Object Manual Differential High/medium differential pressures KDP11/22 OM2-5220-1100 pressures Low-differential pressures KDP33 Very low differential pressure KDP44 Flange type KDP61/62 Remote-sealed type KDP71/72 High working pressure type KDP81/82 Process High pressures...
  • Page 7 Fig. 1-2.
  • Page 8: Chapter 2. Operating Principle

    Chapter 2. Operating principle The input for the transmitter is applied as a torque through the torque tube. The torque causes the gap between the nozzle and flapper to change. The gap change causes the back pressure of the nozzle to change. The back pressure is boosted in both pressure and capacity by the pilot relay in order to be used as an output air pressure.
  • Page 9: Chapter 3. Installation And Operation

    Chapter 3. Installation and operation 3-1. Installation The transmitter (Model K_P) is installed in the state that it is coupled to a detector (meter body). Installation and connection to the process is done by means of the meter body. For installation, refer to the operator’s manual of the meter body used in conJunction.
  • Page 10: Chapter 4. Service And Unit Replacement

    When the meter body is required to be modified due to specification change or application change or due to failure, order your Azbil agent. If it is required to be modified for yourself, order the service tools and Service Manual SM2-5220-0000 “Replacement Procedure of Meter Bodies.
  • Page 11 Name Quantity SCREW VALVE STEM HOUSING GUIDE PIN CONICAL SPRING WASHER SPRING NOZZLE WASHER SEAL DIAPHRAGM (LOWER) EXHAUST RING (OUTER) EXHAUST RING (INNER) AREA PLATE WASHER DIAPHRAGM (UPPER) COVER Fig. 4-1. Pilot relay assembly...
  • Page 12: Chapter 5. Calibration And Adjustment

    Chapter 5. Calibration and adjustment 5-1. General The detector (meter body) feeds a torque, which is proportional to the measured process variable, via the torque tube to the transmitting mechanism of the transmitter. Therefore, regardless of the type of the meter body, the transmitter should be adjusted so that it transmits an output signal of 0.2 to 1.0 kgf/cm linearly proportional to the 0 % to 100 % measuring range.
  • Page 13: Calibration Of Gauge Pressure Transmitter

    (8) If the output pressure is shifted from 100 %, adjust the SPAN ADJ boss at the bottom of the feedback bellows as follows: If the output is higher than 100 %, turn the boss so that the output becomes lower than 100 % by an amount of 1/4 of the shift.
  • Page 14: Calibration Of Absolute Pressure Transmitter

    5-4. Calibration of absolute pressure transmitter (Refer to procedure of 5-3.) To calibrate a transmitter which has a vacuum measuring range alone or which has a compound measuring range including a vacuum range at a substantial rate, use such devices as vacuum pump and needle valve for the variable pressure source.
  • Page 16 Warranty period and warranty scope 1.1 Warranty period Azbil Corporation’s products shall be warranted for one (1) year from the date of your purchase of the said products or the delivery of the said products to a place designated by you.
  • Page 17 Although acceleration of the above situation varies depending on the conditions or environment of use of the products, you are required not to use any Azbil Corporation’s products for a period exceeding ten (10) years unless otherwise stated in specifications or instruction manuals.
  • Page 19 Document Number: OM2-5220-0000 Document Name: Liquid Level Meter Pneumatic Transmitter Model KDP/KKP User's Manual Date: 1st edition: Nov. 1987 6th edition: Jan. 2020 Issued/Edited by:...
