Enclosure Dimensions - Altronix AL176X220 Quick Start Manual

1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
(330mm)
5.10"
(130mm)
3.25"
(83mm)
1.0"
(25mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 1-888-258-7669
web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IIAL176X220 - Rev. 122905
AL176X220

Enclosure Dimensions

13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
1.40" 4.85"
(36mm) (123mm)
0.75"
(19mm)
13.0"
1.0"
(25mm)
(H x W x D) (approximate)
4.85"
(123mm)
12.5"
(318mm)
11.0"
(279mm)
10.5"
(267mm)
H26O
:
1.40"
(36mm)
1.20"
(31mm)
3.25"
(83mm)
0.75"
(31mm)
(19mm)
0.9375"
(24mm)
0.9375"
(24mm)
3.25"
(83mm)
3.25"
(83mm)
1.0"
(25mm)
1.0"
(25mm)
1.20"
1.40"
(36mm)
5.10"
(130mm)
6.5625"
(167mm)
