results. During the test the Micro Plus' display will run through a programmed series
corresponding to the movement of the vehicle. Series: "Pre" - prelude, "br" - brake, "cal" -
calculate. If an error occurs at anytime during the testing, the Micro will display a flashing "Err" for
error. Should this occur, re-start the test.
When the vehicle has come to a halt the Micro Plus will finish the calculations and display the
following results:
To view each results press 'NEXT'. After displaying the results, the display will show "SAV",
press 'YES' to store the results or press 'NEXT' to continue. After that it will display "Prn" to print
the result via IRDA printer (optional accessory). Press 'YES' to continue or press 'NEXT' to go
back to the main menu and display "tst". To perform another test at this point, simply press the
'YES' button again and the Micro Plus will return to its activated status. Simply repeat the test
procedure to complete the testing. You can then simply compare them with the specific brake
values according to your local regulations.

3.5 Test Instructions Summary

Instruction
Prepare Vehicle
Secure the Micro Plus in
vehicle
Switch on Micro Plus
Prepare to Start Test
Test Step 1
Test Step 2
Test Step 3
View Results
Test Step 4
Test Step 5
Test Complete
AUTOSTOP™ Micro Plus User Manual Version 2.21
1. Average Deceleration
2. Maximum Deceleration
3. Speed
4. Stopping Distance
Action
Position vehicle for test
Attach the Micro Plus to the dashboard, front
passenger seat, foot well or centre console so
that the screen is clearly visible and the buttons
are accessible.
Press ON/OFF button
Self Test Complete
Press YES button on Micro Plus
Accelerate vehicle to desired speed
Firmly apply the vehicle brakes until stationary
Calculating the results
The display will show the
Average acceleration
Maximum deceleration
Speed
Stopping distance.
Press NEXT to view each result
Save the test results. Press YES to save or
NEXT to continue.
Print the test results via IRDA printer (optional
accessory) press YES to print or NEXT to go
back to the main menu.
Micro+ Display
"tst"
"go"
"Pre"
"br"
"Cal"
Results displayed
"SAV"
"Prn"
