Temperature Range: -10 to +70 C
Power Range: 9 to 27 volts

5.2 Features

Determines tri-axial deceleration
Calculates and prints the MFDD (Means Fully Developed Deceleration) in accordance with
ECE R13 on IRDA printer or can be viewed on Data logger
Simple three-button operation
Can be installed anywhere in the vehicle
Self-calibrating by identifying its orientation at the beginning of each test
Lightweight ( 500grms), compact
(65 x 140 x 35mm)
7-segment display
Automatic start function
Automatic shut-off after 5 minutes to preserve battery life
Built-in integrity check
Built-in real time clock
Calibration is internationally traceable through NATA
Interval of calibration: 2 years
12 months warranty
Internet support hotline for diagnostics
Comprehensive after-sales service and assistance
EIA RS-232c and IRDA Interface
Memory storage: At least fifteen tests
PC download capability and graph.

6. CALIBRATION PROCEDURE

The Micro Brake Meter must be re-calibrated every two years. The reason for this is to maintain
creditability in tests and acceptance of data according to international standards. Each time the
results are printed, the printout will include the day and month that the re-calibration is due. The
"CAL
unit will also display dUE" if the calibration is due. At the time the unit is due for re-
calibration, the unit will disallow any further testing. There are two ways of calibrating the Brake
Meter - either via your local authorised service centre or by returning the unit to AUTOTEST
Products (See Section 6.1).
6.1 Returning the AUTOSTOP™ Micro Plus for Calibration

6.1.1 Packaging

Please remember that you are shipping an electronic instrument. Bubble pack or foam should
surround the Brake Tester and should be inserted into a sturdy cardboard box.

6.1.2 Shipping

Labelling - A label noting "Electronic Device - Fragile" should be placed on the box.
Freight Carrier – Container should be sent freight prepaid. Auto Test Products has no
preference on freight carriers. However, we prefer companies such as TNT, IPEC, UPS, or
Federal Express forward units, if a prompt delivery is required.
Ship to: The Service Department, Auto Test Products Pty Ltd, 61-63 Parsons St, Kensington, VIC
3207, Australia. Phone: (+61 3) 8840 3016, or to your nearest service distributor.
