VS 900 Quick Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS 900 and is the answer not in the manual?

Questions and answers

Related Manuals for ALIGATOR VS 900

Summary of Contents for ALIGATOR VS 900

  • Page 1 VS 900 Quick Guide...

  • Page 2: Table Of Contents

    Contents Important instructions.......3 Putting into operation.......6 Insert SIM, memory card, battery.....6 Battery charging........7 Switch On / Off..........8 Automatic time setting......9 Description of mobile controls....10 Icons on the screen........16 Making calls..........17 Dialling............17 Answering call by cover opening....18 Phone contacts........18 Photo contacts........19 SOS calls and SMS........19 Starting emergency call and SMS..19 SOS Locator ..........23...

  • Page 3: Important Instructions

    Security...........28 PC connection........28 Safety and ecology.........29 Declaration of conformity......30 Important instructions Thank you for buying of our ALIGATOR mobile phone. Before you start please read carefully this instruction manual.  Do not use the mobile phone in the prohibited areas ...
  • Page 4  Mobile phone can influence the function of the cardiac pacemakers or other implanted appliances – please consult your medical doctor  Switch off the phone in the aircraft.Do not use mobile phone near the petrol stations. Always switch off the mobile phone near explosives ...
  • Page 5 electromagnetic radiation absorbed by your body.  Handle the mobile phone with care, protect it from falling on the ground, from mechanical damage, impurity or high temperatures. Never pick it to pieces !  Do not place the mobile phone or its holder in the area above the airbag in the car ...

  • Page 6: Putting Into Operation

    alter the instruction manual or particular functions of the mobile phone without a prior notice Putting into operation Insert SIM,memory card and battery Slip your nail at the slot under the battery cover on the back side of the mobile phone and pull down carefully the cover.

  • Page 7: Battery Charging

    Insert the battery. The three metal contacts must point toward the bottom of the phone. Make sure that the battery clicks smoothly into the slot in the mobile phone. Put the battery cover back. ATTENTION! Turn off the phone and disconnect the charger when handling the battery, card or SIM card.

  • Page 8: Switch On / Off

    Battery discharged Fully charged Mobile phone will warn you by an acoustic signal and by message on the screen when the battery is almost discharged. In this case charge the battery as soon as possible. Mobil phone can also be charged by placing at the charging stand.

  • Page 9: Automatic Time Setting

    code in case the PIN protection is activated). to SWITCH OFF - press and hold the red button, untill the mobile turns off + press button Yes (2) to confirm it. Before Switching On be sure that the battery is inserted and is charged. Automatic time setting You will be asked to confirm the time after the first switch on of the phone :...

  • Page 10: Description Of Mobile Controls

    Description of mobile controls No Buttons Function...
  • Page 11 -starts contacts in standby mode -return from menu or exit Right current function functional -other functions depending on context button (current function is shown on display above the button) -display Messages in standby mode -confirms selection in menu or activates Left selected function (OK) functional...
  • Page 12 -press Up in standby mode to display phone Navigation menu , press Down to button Up / display photo contacts Down -move in menu and in phone directory -long press to Switch On / Off -stop or reject a call -return from the menu or button exit current function on...
  • Page 13 - long press to switch on the torchlight - insert # when writing numbers - in text writing mode Button # toggles method of character imput - long press to turn on/off silent mode - inserts *,+, p, w when writing numbers - in text writing mode Button...
  • Page 14 Connector serves to connect the charging cable or PC Micro USB powerful LED torch is located on the top edge of the back of the phone. 11 Flashlight Turn the light on / off by long pressing the 0 key long.
  • Page 15 -press to turn the camera On. -acts as a trigger in Shutter camera mode button - in music / recorder mode, etc. press briefly to start / stop playback 16 Buttons -serve as a quick option to store your favorite M1, M2 phone numbers.

  • Page 16: Icons On The Screen

    Icons on the screen Battery charge Signal strength Alarm activated Unread SMS message Missed calls Ringing off...

  • Page 17: Making Calls

    Making calls Dialling Insert required phone number on the mobile keypad and press the green button (5). Mobile will start to dial required number. If you have dialled by mistake a wrong number, just press the right button „Delete“ (1) and the last digit will be deleted.

  • Page 18: Answering Call By Cover Opening

     While talking - press right button On/Off (1) to activate the Handsfree function Answer a call by opening the cover You can set the phone to accept the call by simply opening/sliding the cover and closing it by closing/sliding the cover.

  • Page 19: Photo Contacts

    Select Contacts – New Contact – to create a new contact at the phone. Photo contacts The phone can store up to 10 so-called photo contacts - that is, contacts to which a photo or picture is assigned. You can then quickly and easily dial them by selecting an image.
  • Page 20 the list until they can call one. The phone repeats calls to all numbers for a max.3x The phone also sends an emergency SMS message to the preset numbers with the preset text (to select text in the menu) Setting  SOS Set..  SOS SMS SMS text.
  • Page 21 should automatically call and send SMS message to. For set up select in menu : Settings  SOS Set. Deactivation of sending SMS message It is possible to deactivate the sending of SMS messages after the activation of the SOS button. Select in menu : ...
  • Page 22 Just "click" on this link and a map showing the position of the phone displays. The location is determined based on the focus of the network operator, the accuracy is dependent on the density of the network at a given position, eg. in the cities the position can be determined with an accuracy of tens to a few hundred meters, outside the buildings/cities but a...

  • Page 23: Sos Locator

    SMS. It is sufficient to send just a command via SMS with a text SOSLOCATOR. Your ALIGATOR phone then responds by sending of the current position via SMS. Important: Your phone sends location and responds only to SMS messages on...

  • Page 24: Setting Of Sos Function

    numbers that are stored at the mobile phone for SOS emergency calls ! Setting of emergency SOS functions To set up the SOS Locator select in menu : Settings  SOS Set. An offer is displayed : SOS regime – enables to switch SOS function.

  • Page 25: Sms Messages

    emergency SMS messages and set the text of emergency SMS Siren – allows to run the siren after pressing the SOS button SOS numbers - sets up to five numbers to which the phone sends an emergency SMS and tries to call after activating the SOS button SMS messages Your phone can receive and send SMS...

  • Page 26: Fm Radio

    FM Radio Your mobile phone is equipped with FM Radio. Select in menu : Multimedia  FM Radio Press the volume buttons (14) to adjust the volume.You can change the frequency using the M1 / M2 (16) keys. Press the shutter button (15) repeatedly to turn the sound on / off.

  • Page 27: Sim Toolkit

    It is possible to transfer call sound or send files or receive files from another device. Select in menu: Settings  Connection Bluetooth SIM toolkit Choose in menu: Organizer  SIM Toolkit - for mobile banking, timetables and other SIM services of your operator. Photo camera The camera lens is located on the back side of the phone cover.

  • Page 28: Mobile Phone Settings

    Mobile phone settings Select in menu: Settings  Phone Allows you to set basic phone parameters: Security Select in menu : Settings - Security enables to set up PIN code of SIM card, phone password. Default password from production is 1122. Connection with PC (and battery charging as well) via USB connector...

  • Page 29: Safety And Ecology

    Safety and ecology Used electric device Mobile phone is an electronic appliance. It means it must NOT be manipulated as a common residential waste. Never throw the used device away at the common municipal waste!!! They may contain the substances dangerous to the environment.

  • Page 30: Declaration Of Conformity

    Handling with the used batteries in contradiction with given instructions is illegal! Declaration of conformity ADART COMPUTERS s.r.o. declares that the type of ALIGATOR VS 900 radio device is in compliance with Directive 2014/53 / EU. Importer: www.aligator.cz Copyright © 2017 ADART COMPUTERS...
