MIMAKI JVS4 Series Quick Reference

QUICK REFERENCE
TYPES OF INK
• Be sure to use the inks and ink cartridges specified by MIMAKI.
• Water-soluble pigment ink [Pigcm]
• Water-soluble pigment ink [PigOG]
• Water-soluble dye ink [Dye]
• Disperse dye ink [Sub]
FILLING INK FOR THE FIRST TIME AFTER PURCHASE OF PLOTTER
INITIAL SETTING OF INKS
1. Turn the power on.
After the initial operation, the device displays the type of ink set in
each ink station.
2. By pushing the JOG keys [ ] and [ ], specify the
type of ink set in the R-row ink station.
[Pigcm] Water-soluble pigment ink (light cyan, light magenta)
[PigOG] Water-soluble pigment ink (Orange, Green)
[Dye] Water-soluble dye ink
[Sub] Disperse dye ink
3. Move the cursor by pushing the JOG keys
[ ] and [ ].
4. By pushing the JOG keys [ ] and [ ], specify the
type of ink set in the F-row ink station.
5. Press the [ENTER] key.
6. Insert the ink cartridges into the ink stations.
Align two projecting portions of the ink cartridge with rails on the ink
stations. Once the ink cartridge is inserted to reach the normal
position, the buzzer will sound.
Insert the respective ink cartridges into the corresponding ink
stations.
7. The print head is automatically filled with ink.
8. Once the ink-filling procedure completes, the
device enters the LOCAL mode.
INK FILLING GUIDE
- 1 -
INK TYPE
R : Pigcm F : Dye
INK TYPE
R : Dye F : Dye
INK TYPE
R : Dye F: Dye
INK TYPE
R : Dye F : Pigcm
CARTRIDGES SET
FILL UP
<< LOCAL >>
D200588
