CHILD SAFETY

INSTALLATION INSTRUCTIONS
Be aware that it is possible for children to strangle in window
covering cords. To reduce the possibility of such an accident, all
cords must be kept out of the reach of children, including
infants. Cord cleats are an effective way to implement this
essential precaution.

INSTALL CORD CLEATS

Attach the cord cleats 153mm to 305mm apart at a height at
least 1600mm above floor level to prevent children from
unwinding the cord from the cleat. Take into account that a child
may stand on a baby cot or other furniture in an attempt to reach
the cords. Once the cleats are attached, simply wrap the excess
cord around them after each use of the shade, as shown.
Cord Cleat

OPERATION

CORD TILT: Pulling on one of the single cords will tilt the slats
in one direction, and pulling the other cord will tilt the slats in
the opposite direction.

RAISING AND LOWERING OF THE BLIND:

Important:
Standard Blinds: whenever raising or lowering the blind, the
slats should be in the open position.
The cordlock has a locking device that holds the cords in place
when they hang vertically down. To raise or lower the blind, pull
the double cords towards the middle until you hear the
cordlock disengage. When the blind is at the desired height,
return the cord to the side of the blind to re-engage the
cordlock.

CARE AND CLEANING

1. Dust can be easily brushed off at regular intervals using a
clean soft cloth, a feather duster or a vacuum cleaner with
brush attachment.
2. To dust, tilt slats up and then down, (but not entirely closed),
to reach the top and bottom surfaces.

ADDITIONAL INSTRUCTIONS

Oiled Cedar
Oiled cedar blinds require re-oiling every 12 months, to
rejuvenate the appearance, and stop the timber drying out and
cracking.
We recommend Cabots Danish Oil (Cedar interior finish)
available from hardware stores. Follow the application
instructions on the tin. Take care not to oil string or fabric tapes
and cords.
Lacquered Cedar and Stained & Lacquered Basswood
Regular application of furniture polish applied with a soft cloth
is required. Follow the manufacturer's instructions on the best
application method. Lemon Oil is also suitable to rejuvenate
the surface.
Polishes for high gloss timber are not suitable.
We recommend Spray Glow Furniture Polish from Mirotone.
It can be purchased from Mirotone on Ph (02) 9795 3700 or
Fax (02) 9771 3601.
WARNING: Do not allow water to come into contact with
the timber. Although the timber is coated, if water comes
into contact with the timber it can cause the slats to warp,
bow or twist, water stains to occur or the paint or lacquer
to peel. Do not use a damp cloth when cleaning. Damage
to the blind caused by water is not covered under the
warranty.
WOODMATES
®
Blinds, BEYOND WOODS
• Light dusting and/or use a vacuum cleaner with brush
attachment.
• Wipe with damp sponge or cloth.
• Fully washable. Do not immerse the headrail.
© Copyright 2010 Hunter Douglas Limited [ABN 98 009 675 709]
® Registered Trade Marks of Hunter Douglas Limited
TIMBER VENETIAN BLINDS
WOODMATES
BEYOND WOODS
NOVA WOODS
COUNTRY WOODS
INSTALLATION
INSTRUCTIONS
®
Blinds,

DISCLAIMER

This Installation Instructions Pamphlet ('the pamphlet') is only a
guide to the set up and maintenance of your Timber Venetian Blinds
and Hunter Douglas Limited ('HDL') does not warrant the accuracy
of the information contained in the pamphlet. Each Installer of the
Timber Venetian Blinds must rely upon their own skill and expertise.
The pamphlet is based on general data pertaining to the
construction, material properties and working methods known to us
at the time of issue and is therefore subject to changes or
amendments at any time without notice and the right to change or
amend is hereby expressly reserved by HDL.

MATERIAL AND TOOLS

Each Venetian Blind ordered should include:
• 1 left hand and 1 right hand hinged cover mounting bracket
• Support bracket(s) if needed
• 2 screws for each bracket (20mm x 6# Panhead)
• 1 pair of hold down brackets
• Safety Cleats

TOOLS REQUIRED

• Steel measuring tape
• Carpenter's level
18.609.024
11/2010
• Power or battery drill and bits
• Flat blade and Phillips head screwdrivers
BLINDS
®
BLINDS
®
VENETIANS
®
VENETIANS
®
