Duette
®
Honeycomb Shades
Corner Cover
Inside Mount
Installation
Bracket
Side
Rail
(Left)
Outside Mount
Installation
Bracket
SPECIFICATIONS
Minimum Width 12"
Maximum Width 96"
Minimum Height 12"
Maximum Height
Varies based on width of shade
Extension Pole Sizes 6' or 10'
Hardware Colors
Aspen White, Bronze, Gardenia White
Mounting REQUIREMENTS
Inside Mount 2-1/2" depth minimum
Outside Mount Surface Height 1-1/4" minimum
Recommended width overlap per side 2"
CRANK HANDLE (must be specified)
CLEARANCE NEEDED
Below Bottom Rail 1-1/2" Height
Depth in Front of Bottom Rail 1" Depth
SkyLift™ Manual
Tension Screw
and
Top Tension
Top Rail
Plate
Tension
Cable
Bottom Tension
Plate and Screw
Control Knob
Bottom Rail
Moving
Rail
Spacer
Blocks
Crank Handle (Optional)
Hunter Douglas Hospitality's products
mounting points. Suitable mounting
surface and structural support where
Top
Corner
Bracket
Moving
Rail
End Cap
R
Bottom
Corner
Bracket
Extension Pole (Optional)
vary in weight and require specific
needed is to be provided by others.
082919
Side
Rail
(Right)
