Summary of Contents for Hunter Douglas Vignette Tiered
- Page 1 Installation Operation Care • • Vignette Modern Roman Shades ® Tiered Style Shades ™ PowerView Motorization ™...
-
Page 2: Table Of Contents
Warning ..............21 Declarations .............. 22 Warranty ............Back Cover Questions? Call the Hunter Douglas Customer Information Center at 1-888-501-8364. © 2016 Hunter Douglas. All rights reserved. All trademarks used herein are the property of Hunter Douglas or their respective owners. -
Page 3: Getting Started
GETTING STARTED Product View Power 18V Battery Wand Cable Battery Wand Clip Manual Control Button Installation Brackets with Spacer Blocks Standard Top-Down/Bottom-Up Fabric- Covered Headrail Middle Rail Bottom Rail Magnetic Hold-Down Brackets (Optional) Not Shown: Two-on-One Headrail Shade... -
Page 4: Tools And Fasteners Needed
GETTING STARTED Thank you for purchasing Hunter Douglas Vignette Modern Roman Shades with PowerView ™ ® Motorization. With proper installation, operation, and care, your new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. -
Page 5: Installation
INSTALLATION Installation Overview To install your shade, you will need to perform the following three steps: STEP 1: Install the Brackets STEP 2: Install the Shade STEP 3: Connect the Power Source STEP 1 — Install the Brackets Shade Width Brackets 12"... - Page 6 INSTALLATION Mount the Installation Brackets — Inside Mount Mark 2" in from each jamb for bracket location. ■ If more than two installation brackets came with your order, space additional bracket(s) ➤ evenly between the two end brackets. Mount into wood whenever possible. With shades using a battery wand, there must be a minimum of 15"...
- Page 7 IMPORTANT: Spacer blocks are recommended for rear fabric fold clearance. Add " for standard Vignette Tiered or 1" for Vignette Tiered Architella . (With shades using a ® ™ ® battery wand, an absolute minimum of "...
- Page 8 " for standard Vignette Tiered or 1" ® ™ for Vignette Tiered Architella . (With shades ® using a battery wand, an absolute minimum Screw " added clearance is required.) If using extension brackets, attach an installation ■...
- Page 9 INSTALLATION Mount the Installation Brackets — End Mount End mount the headrail when conventional mounting techniques will not work — for example, in an arched window. Mount the extension brackets on a surface at least ■ " wide. Be sure to allow for rear fold clearance, which also allows for battery wand clearance.
-
Page 10: Step 2 - Install The Shade
INSTALLATION STEP 2 — Install the Shade If You Have a Battery Wand Clip... (For DC power supply or satellite battery pack installations, go to “Mount the Headrail” below.) Attach the battery wand clip to the headrail. ■ IMPORTANT: Position the clip so that the battery wand will be between installation brackets. A minimum of 15"... -
Page 11: Step 3 - Connect The Power Source
If You Have a Battery Wand... Install Batteries Into the Battery Wand NOTE: Hunter Douglas recommends AA alkaline batteries for use with our battery-powered shades. These will provide more than one year of operation, depending on usage. Lithium and rechargeable batteries are not recommended. - Page 12 INSTALLATION Plug the Power Cable into the Battery Wand On the back of the headrail, connect the power cable ■ Back of Shade from the shade into the socket on the battery wand. Check the Power Cord Visible Wire Check the headrail to ensure the power cord is not visible. ■...
- Page 13 INSTALLATION Install the cover with the slot aligned to the socket in the battery wand. ■ Battery Wand Cover Slot Socket Plug the power cable from the shade into the ■ Battery Wand Cover extension cable. Extension Plug the other end of the extension cable into ■...
- Page 14 INSTALLATION WARNING: Keep cords and small parts out of the reach of children. They can wrap cords around their necks and STRANGLE. They can also put small parts in their mouths and CHOKE. WARNING: Electric shock and/or a fire hazard may occur if the DC power supply and cables are not properly installed.
-
Page 15: Attach Magnetic Hold-Down Brackets (Optional)
INSTALLATION Attach Magnetic Hold-Down Brackets (Optional) Completely lower the shade. ■ Magnetic Attach the magnetic hold-down bracket onto the bottom rail ■ Hold-Down Bracket just inside the end cap, oriented as shown. Mark the screw locations using one of the mounting options ■... -
Page 16: Operation
OPERATION Testing the Shade Test the Shade Using the Manual Control Button Testing the shade with the manual control button will allow you to ensure that the motor and power source are working correctly. Manual Press the manual control button on the motor side end ■... - Page 17 OPERATION Joining a Shade to a Group IMPORTANT: The shade will not operate using the remote until it has been joined to a group. 1. Press and hold ■ STOP for 4 seconds to put remote in program mode. The lights on the remote will flash to indicate it is in program mode.
-
Page 18: Resetting The Shade
OPERATION Further Operation and Programming Information PowerView Pebble Remote and/or PowerView Surface Remote Operation ™ ™ For information regarding operation and programming of the PowerView remote, refer to your PowerView Motorization Remote Control Guide. PowerView Scene Controller For information regarding operation and programming of the PowerView Scene Controller, refer to your PowerView Motorization Scene Controller Guide. -
Page 19: Troubleshooting
First review the guide that came with your control device. ■ Refer to the following troubleshooting for specific solutions for your shade. ■ If questions remain, please contact the Hunter Douglas Customer Information Center at 1-888-501-8364. Problem The shade will not snap into the installation brackets. - Page 20 OPERATION Problem The shade is hard to raise or lower, or will not raise or lower. Solution Make sure the fabric is not caught in the installation brackets. Check that the headrail and installation brackets are level and aligned in the window.
-
Page 21: Care
IMPORTANT: On longer shades, you might need to lower the shade slightly to access the locking tab. Cleaning Procedures Hunter Douglas Vignette Modern Roman Shades are made with anti-static, dust-resistant ® fabrics that repel dirt and dust. For most fabrics, the following cleaning options are available. - Page 22 CARE Ultrasonic Cleaning Vignette Modern Roman Shades can be ultrasonically cleaned by a professional. ® CAUTION: Do not ultrasonically clean the headrail, middle rail or bottom rail fabric, or any room-darkening fabrics. Specify that a mild detergent solution be used. ■...
-
Page 23: Child Safety
CHILD SAFETY WARNING For more safety information call 1-888-501-8364 in the U.S. or 1-800-265-8000 in Canada. Always keep cords out of the reach of children. ■ Move cribs, playpens and other furniture away from cords. Children can climb ■ furniture to get to cords. NOTE: The warning labels on the bottom rails of corded window coverings contain important safety information. -
Page 24: Declarations
This Class B digital apparatus complies with Canadian ICES-003, RSS-Gen and RSS-210. CAN ICES-3 (B)/NMB-3(B) European Conformity We, the undersigned, Hunter Douglas Window Fashions One Duette Way, Broomfield, CO 80020, USA Hunter Douglas Europe B.V. Piekstraat 2, 3071 EL Rotterdam, The Netherlands certify and declare under our sole responsibility that assemblies PV1 and PV5 conform with the essential requirements of the EMC directive 2004/108/EC and R&TTE directive 1999/5/EC. - Page 25 Notes...
- Page 26 Notes...
-
Page 28: Warranty
2. Visit hunterdouglas.com for additional warranty information, frequently asked questions and access to service locations. 3. Contact Hunter Douglas at (888) 501-8364 for technical support, certain parts free of charge, for assistance in obtaining warranty service or for further explanation of our warranty.
