Installation and
Programming
Instructions
Motorized Shades
THANK YOU for purchasing a Hunter Douglas
Remembrance
®
motorized window shade. Your new
shade has been custom built for you from the highest
quality materials. Once in your window, it will provide
you with a lifetime of beauty and trouble-free use.
Getting Started
Hunter Douglas will ship your motorized shade with:
• Motorized shade installation hardware.
• Pre-set up and down limits.
• Remote or switch pre-programmed.
Remove the shade from the package and check the
diagram to make sure you have the necessary parts.
Keep the packaging until the shade operates to your
satisfaction.
������� ����
������������ �������
� ��� �����
Remembrance
®
Motorized Shade
with Cassette
Tools needed for installing your shade:
• Carpenter's Level
• Measuring Tape
• Power Drill and Drill Bits
In addition, you will need fasteners designed to work with
your specifi c mounting surfaces:
Mounting
Surface
No. 6 Hex Head Screws
Wood
(Provided)
Sheet Metal Screws
Metal
(Not Provided)
Application not recommended due to
Drywall, Plaster
extreme weight of shade(s)
Contents of your hardware package may vary depending on how
the shade was ordered and whether the shade will be mounted
inside or outside the window opening.
���� �����
������������ �������
Remembrance
®
Motorized Shade
• Flat Blade Screwdriver
• Phillips Screwdriver
Fastener
